Unifin International, Inc.
London, ON N6A4P4
Mar 19, 2007 Installed on transformer, ForZair(TM) HeatSink auxiliary coolers immediately reduce temperature of dielectric cooling oil. Units can be transferred from one overloaded substation to another, providing relief wherever it is needed most. They employ mono-aluminum extruded fin-tubes and Cardinal transformer oil pumps with glandless design that prevents leaks. To augment cooling on 1-60 Mva OA, FA, or FOA transformers, coolers come ready for fully self-contained operations.

Lochinvar Corp.
Lebanon, TN 37090
Mar 13, 2007 Available in 5 commercial models with inputs from 150,000-500,000 BTU/hr, ARMOR Water Heater is designed to be installed with separate storage tank for protection against harmful effects of lime scale buildup. Along with stainless steel heat exchanger, product is equipped with fully modulating 5:1 turndown burner and SMART SYSTEM(TM) control with built-in cascading sequencer. Water heater can be vented using PVC or CPVC pipe and permits direct-vent distances up to 100 ft.

Georg Fischer Piping Systems
Tustin, CA 92780
Mar 12, 2007 Suited for 300 mm semiconductor manufacturing plants and applications in chemical and microelectronics markets, SYGEF® PVDF Exhaust Piping System enables safe conveyance of aggressive exhaust gases and fumes. It includes pipe sizes from 2-½ to 16 in., and various fittings, reducers, fixed flanges, gaskets, seals, and throttle valves. Other features include UV-resistance, operating temperature range from -4 to 284°F, and vacuum rating of 0.218 psi, 6 in. wc.

AMETEK Test & Calibration Instruments
Largo, FL 33773
Mar 08, 2007 Capable of reaching temperatures from -90 to +125°C, JOFRA(TM) ATC-125 Ultra Cooler incorporates ATC Series dual-zone control technology to ensure precise temperature homogeneity throughout calibration well. Unit achieves cryogenic temperatures through Free Piston Stirling Cooler technology, which consists of Stirling heat pump in 290 g, compact unit. Helium gas acts as heat transport medium, while mains power variance immunity technology promotes temperature stability.

Kaeser Compressors, Inc.
Marietta, GA 30067
Mar 07, 2007 Sigma Air Manager Basic (SAM Basic) master controller provides pressure band control, balances service hours, tracks preventive maintenance requirements, and prevents simultaneous motor starts. It can be adapted to almost any system and manage up to 4 compressors or vacuum pumps. Controller also connects to dryers, filters, and drains to monitor operating or maintenance status.

Moore Industries International, Inc.
North Hills, CA 91343
Mar 06, 2007 BIMETAL Dual-Mode Remote Thermometer offers on-site indication of process temperature conditions while simultaneously providing mV or ohm signal proportional to temperature for input to another device. Solution requires no power supply at point of measurement and includes thermowell probe assembly, which contains RTD or thermocouple sensor and analog display that are NIST-traceable and can be calibrated in-field. Dials are available to indicate 0 to +250°F and 0 to +500°F ranges.

TEK-TEMP INSTRUMENTS, INC
Croydon, PA 19021
Mar 05, 2007 Available with cooling capacities up to 4,800 BTU/hr, LK-20 Series features low-profile design that permits installation in space-restricted areas. Series measures 15 in. high (17 1/8 in. with casters) and offers self-contained and tethered controllers that provide stability to 0.1°C over 5 to 35°C range (up to 80°C with heater option). All-stainless steel plumbing and cabinets are compatible with many process fluids and operating environments.

AMETEK Commercial Motors
Kent, OH 44240
Feb 28, 2007 Offered with max diameter of 5.7 in. and heights from 5.30-6.87 in., IntelliGen(TM) series has sealed vacuum capabilities to 120 in. H20 and max wide-open flow to 280 cfm. Electronic drive controller incorporates DSP, offering customization capability to meet specific requirements. Each unit may be programmed to maintain constant pressure over wide range of flow or accurately maintain ratio of specific speed/output pressure to user's speed command input signal.

S & S Tech Pentamagnetics
Walnut, CA 91789
Feb 27, 2007 Suited for air moving and HVAC industries, Brushless Electric Fan features advanced fan blade technology that can be sized from 10-18 in. diameter with full documentation of power and airflow characteristics. Based on 3.8 in. diameter x 2.5 in. long motor, fan produces max airflow of 2,700 cfm and max static pressure of 1 in. water. Higher output can be achieved through rapid-design program. Models are available in 12, 24, 36, 48, 115, and 230 V.

Dometic Corp., The
Elkhart, IN 46516
Feb 27, 2007 Self-contained, water-cooled Turbo Series includes multiple models ranging from 6,000-16,000 btu. Design incorporates positive-flow composite condensate drain pan that minimizes standing water, and centrifugal enclosed-motor HV blower that can be rotated up to 270° with single-screw adjustment for discharge in any direction. Built-in isolation mounting system minimizes vibration and noise.

Fette America
Rockaway, NJ 07886
Feb 21, 2007 Equipped with self-cleaning HEPA filter, Cephir safely removes and contains high volumes of extremely fine dust particulates from exhaust air of production machines in variety of industries. Measuring 40 x 30 x 90 in., unit features parallel swing doors, pull-out control cabinet, and bag-in bag-out filter exchange. It also includes control interface MES/SCADA system, filter cassette with leak test gasket, and blower with variable frequency drive.

AAF International
Louisville, KY 40223 6169
Feb 21, 2007 ArrestAll AR Series self-contained shaker-type dust collector is painted inside and out with powder-coat finish for corrosion-resistance. Featuring hinged side-access door with single access and self-aligning locking mechanism, device includes fan, motor, filter envelope, and automatic shaker unit. Shaker control allows for time and fan coast adjustments from 0.6-60 sec. ArrestAll filter is available with standard 16 pocket or extra wide 8 pocket spacing.

Dwyer Instruments, Inc.
Michigan City, IN 46361 0373
Feb 15, 2007 Series 4C 1/4 DIN Temperature Controller supports ON/OFF, PID, auto-tuning, and manual tuning, as well as variety of thermocouple and RTD inputs. Process value and setpoint value are simultaneously displayed on dual LED, while output status, alarm status, auto-tuning, and engineering units can also be viewed on faceplate. Unit is available with relay, voltage, or current output with two additional alarm outputs.

Emerson Network Power
St. Louis, MO 63136
Feb 15, 2007 Liebert TCDV air-cooled, direct-drive refrigeration condenser, suited for cooling systems with dual refrigeration circuits, features variable-frequency drive that controls speed of primary fan based on refrigerant pressure variations. Pressure control can be maintained for outdoor ambient temperatures as low as -20°F, and unit can respond to changes as small as ±1°F and ±1% RH. Condenser also features transient voltage surge suppression to protect electronics.

K&B Duct
Greensboro, NC 27409
Feb 14, 2007 Designed to hasten installation and facilitate system modification, Clamp-Together Duct is available in 24-10 gauge thick galvanized or stainless steel in 1 in. dia increments from 3-24 in. It is assembled with lifetime-guaranteed Forever Clamp and suited for any negative-pressure ventilation system up to 40 in. wg with entrained dust, sand, fumes, mist, smoke, chips, or trim scrap. Adjustable sleeves and components enable field fitting to any length.

Greenheck
Schofield, WI 54476 0410
Feb 13, 2007 With no tie-downs to roof, high-wind and hurricane exhaust fans feature structural bracing on interior and exterior of fan as well as high-wind roof curb. Models H-G direct drive and H-GB belt drive fans, designed for general exhaust applications, feature performance ranges up to 14,000 cfm and up to 2.75 in. wg. Suited for restaurants, models H-CUE direct drive and H-CUBE belt drive fans range up to 14,700 cfm and up to 5 in. wg.

Mokon
Buffalo, NY 14207
Feb 13, 2007 Hydrotherm II circulating water temperature control system has 25 gpm pumping capacity, 9 kW heating capacity, maximum operating temperature of 250°F, and occupies 2 sq ft of floor space. With 2-pass stainless steel heating canister, fluid is forced to take designed path over heating elements to increase heat transfer efficiency. System includes control panel with lights indicating mode of operation and microprocessor-based controller for precise temperature control.

Georg Fischer Piping Systems
Tustin, CA 92780
Feb 13, 2007 Mounted into 2-48 in. pipe without system shutdown, Signet 2552 Metal Magmeter can measure flow in fluids containing particles, solids, and fibers. Design permits hot-tap access to pipe stream and is built of corrosion-resistant materials. Along with frequency, digital, and 4-20 mA output choices, sensor offers empty pipe detection and bidirectional flow capabilities as well as linearity of ±1% reading. Dynamic flow range is 0.15-33 fps, with repeatability of ±0.5% of reading at 25°C.

Mokon
Buffalo, NY 14207
Feb 13, 2007 Available in 10-500 ton capacities, Outdoor Air-Cooled Central Chillers incorporate microprocessor-based chiller control technology. Chillers are factory wired and tested, and arrive on site in complete working order. Units feature air-cooled condenser with direct drive vertical condenser fans, and operate in outdoor ambient temperature range of 0-115°F.

Harwil Corp.
Oxnard, CA 93030
Feb 09, 2007 Fit into existing pipes or offered in PVC Tees, TS-1N and TS-1CR can signal computer to activate electrical response when fluids reach critical temperature settings between -20 and +200°F. Model TS-1N works with water, salt water, mild acid, and base solutions, while TS-1CR suits more corrosive materials. There are 4 available electrical connection options, and high/low temperature sensitive switches can be customized to specifications.
