Hart Scientific, Inc.
American Fork, UT 84003 9775
Sep 05, 2007 Platinum resistance thermometer (PRT), model 5609, is 100-ohm sensor with -200 to +670°C range as well as short-term repeatability and long-term drift of ±0.01°C at 0°C. This secondary reference temperature sensor can be ordered in ¼ in. or 6 mm dia versions to meet international demands. While standard sizes come in sheath lengths of 12, 15, or 20 in., metric versions come in sheath lengths of 300, 400, or 500 mm.

Sly, Inc.
Cleveland, OH 44101
Sep 04, 2007 RAC Series Reverse Air Collectors removes accumulated dust from filter bags without requiring compressed air. They feature internal blower and heavy duty ¾ hp explosionproof gear drive motor to move cleaning arm. High-velocity nozzles direct air for continuous cleaning of each filter bag on every rotation. System also features walk-in clean air plenum, 10 ga carbon steel construction, snap band top load filter bags, and heavy duty 12-wire cages made of 11 ga galvanized wire.

Salisbury Electrical Safety, LLC
Skokie, IL 60077
Sep 04, 2007 Mounted to short and full brim hardhats, PRO-AIR(TM) ACAIR3000(TM) provides forced ambient air throughout headwear to keep workers cool. Microprocessor-controlled unit, powered by rechargeable batteries, offers automatic and manual functions. Also available, ACAIR2000(TM) is designed for arc flash hood applications. It provides continuous air supply to worker while reducing hazardous effects of shield fogging. Rechargeable batteries offer 3 hr of continuous operation per charge.

Spectrum Sensors & Controls, Inc.,
Grass Valley, CA 95945
Aug 31, 2007 To accurately monitor air temperature within enclosure, Air Temperature Sensor's thermistor element is integrated into potted metal housing that can be securely snapped into 0.30 in. diameter pre-drilled hole in sheet metal. This keeps sensor off sheet metal while plastic molded body separates assembly from environment on backside. Equipped with 10 ft, AWG 22 PVC insulated leads, sensor features standard resistance values from 2,252-10,000 W at 25°C.

ThinGap LLC
Ventura, CA 93003
Aug 31, 2007 Based on electromotive coil technologies, NEMA 23 size Centrifugal Fan/Blower Motor provides 85 oz-in. continuous torque at 16,300 rpm, while operating at 80 V and 17.65 A, including amplifier losses. By replacing iron core and wire windings of conventional motors with precision machined copper sheet, issues such as hysteresis, cogging, and iron losses have been eliminated.

Hart Scientific, Inc.
American Fork, UT 84003 9775
Aug 30, 2007 Available with 9 or 12 in. long sheath, model 5608 high-temperature platinum resistance thermometer (PRT) features 1/8 in. sheath diameter and special design that lend to short-term repeatability of ±0.02°C from -200 to +500°C in 3.1 in. of immersion. This 100 ohm sensor is available with certificate of compliance or NVLAP-accredited calibration. Options include sensor characterization or full system calibrations, which include performance of sensor and readout together.

Weed Instrument Co., Inc.
Round Rock, TX 78680
Aug 29, 2007 Designed and tested to be installed directly into bypass of primary coolant loop of pressurized water reactors, Model N9355 RTD is environmentally and seismically qualified to RCC-E K2 equipment qualification standard. Unit withstands severe vibration and shock, while providing time response of 1.5 sec or less. Material selection and external wire wound element design ensure low drift at elevated temperatures and high vibration.

Banner Engineering Corp.
Minneapolis, MN 55441
Aug 28, 2007 Thermocouple and RTD Instrumentation Nodes support thermocouple/thermistor inputs and 2-, 3-, and 4-wire RTDs. Offered with 11 configurable thermocouple options for temperature sensing range from -200 to +2,320° C, SureCross thermocouple node supports up to 3 thermocouple inputs, 1 thermistor input, and 2 discrete inputs, and has 2 discrete outputs. RTD node supports up to four 3-wire Pt100 (DIN .00385) RTDs and offers temperature sensing range of -200 to 482°C.

MKS
Andover, MA 01810 2449
Aug 20, 2007 Maintaining ion balance of less than ±1 V or better with external monitor and less than ±3 V without, Ion Systems Critical Environment In-tool Ionizing Blower Model 5822i is suited for ESD control in process tools used in hard disk drive, backend semiconductor, and other automated manufacturing environments. It features internal automatic balance correction system, collimator, separate control box, and Hydro Wave bearing fan facility monitoring system connection.

Sealant Equipment & Engineering, Inc.
Plymouth, MI 48170-0965
Aug 17, 2007 Peltier series Thermoelectric Temperature Controller combines Peltier thermoelectric device, temperature sensor, and temperature control mounted to manifold where fluid passes through to be heated, maintained, or cooled. Mounted in-line or on fluid dispensing equipment, product uses Peltier-Seebeck effect to directly convert electrical voltage to thermal differentials and heat or cool fluid materials to temperature set point. Accessories are available.

Omega Engineering, Inc.
Stamford, CT 06907
Aug 17, 2007 Powered by 4 standard alkaline AA or rechargeable batteries that provide at least 5 hr of continuous use, HHTFO-101 lets operators move about freely in order to measure temperatures at various critical sensing points. Single-channel instrument, equipped with LCD and RS232 com link, is CE-compliant and available with optional Windows software. Suited for multiple applications, this data logger comes with universal charger and 4 AA NiMH batteries.

Lochinvar Corp.
Lebanon, TN 37090
Aug 16, 2007 KNIGHT wall-mounted fully modulating condensing heating boiler features 5:1 turndown burner and adjusts heat output according to demand. Boiler offers an efficiency rating of at least 93%, and permits intake with venting running up to 40 feet using 2 in. pipe. Also features Smart System operating control with user-friendly interface, outdoor reset with sensor, three pump control, night setback, and password security. Optional software enables recording, tracking, and data analyzation.

Torrey Pines Scientific, Inc.
San Marcos, CA 92069
Aug 16, 2007 Peltier-driven and fully programmable, EchoTherm(TM) IC35 Series stores 5 programs in memory - with 10 steps per program - for instant recall and use. Each program can be made to repeat automatically from 1-99 times. Heavy-duty dry bath models IC35 (-10 to +100°C) and IC35XT (-20 to +100°C) can freeze, chill, or heat samples in variety of sample blocks that hold 0.5-50 ml centrifuge tubes, test tubes, vials, assay plates, and round-bottom flasks. Each measures measure 8.5 x 10 x 4 in.

Lab Fabricators Co.
Cleveland, OH 44103
Aug 14, 2007 Featuring redesigned air plenum and directional air vanes, 90% Energy Efficient Fume Hoods create uniform, low-velocity air curtain that contains and carries away fumes inside hood to rear exhaust port. Supplemental air is not forced down and on to hood operator. Combined supplemental air and exhaust air form push-pull effect that requires minimal energy power consumption of conditioned room air while offering maximum protection to lab personnel from toxic fumes.

Ruwac Industrial Vacuums
Holyoke, MA 01041
Aug 08, 2007 MicroClean filtration system for portable vacuum line features manual quick release assembly that drops accumulated concrete dust from filter. Design keeps filter integrity intact to ensure dust-free operation and dustless environments for concrete workers. Available as upgrade for any existing portable machine for concrete dust recovery, dry-material filter assembly is included with all vacuums.

Continental Fan Mfg. Inc.
Buffalo, NY 14215
Aug 06, 2007 Available in diameters from 12-42 in., ADD Tube Axial Fan is constructed with heavy-duty, welded steel housing and angle ring flanges, with spark-resistant, cast aluminum airfoil axial impeller. Unit is powered by TEFC industrial duty motor and includes externally mounted and wired junction box. Mountable in ductwork in any position, fan is suited for process ventilation, in-line duct boosters, general ventilation, and fumes, dust, or smoke removal.

RBI Water Heaters
Westfield, MA 01085
Aug 02, 2007 LCD Dominator(TM) Series uses sealed combustion chamber, alloy burners, and multi-speed blowers for efficient staging. Sealed combustion chamber provides flexibility of using outside air or mechanical room air for combustion. Available as indoor/outdoor units, jacketed boilers feature construction that promotes ease of serviceability. Series includes 12 models with range of 225-2,300 MBH.

ITW
Glenview, IL 60025
Jul 26, 2007 Model FXBC10 has 10 kg capacity and can blast chill product from 70ºC to 3ºC within 90 min to maintain food quality and ensure HACCP food safety law compliance. Chiller enables left-over food from hot servery counter to be quickly and safely chilled for later use with complete confidence in its quality and safety. Suited for restaurateurs, hoteliers, and publicans, it also aids in advance food preparation by chilling larger batches for later use.

Allegro Industries
Garden Grove, CA 92841-1410
Jul 20, 2007 Featuring portable design with carry handles and shoulder strap attachment, Air Bag Blower Systems are available with 8 or 12 in. metal blower, each with 9-blade fan and steel construction. Air Bag 8 features ¼ hp motor and delivers up to 700 cfm, while Air Bag 12 is equipped with ½ hp motor and produces 1,800 cfm. Both units contain single-ply vinyl/polyester PVC coated ducting. Zippered ends allow blower use without removing blower from carry bag.

Mettler Toledo, Inc.
Columbus, OH 43240
Jul 19, 2007 Offering at-a-glance characterization, RTCal(TM) provides process R&D chemists and engineers with tool that can be used alone or together with heat flow method to provide additional data. Measurement is based on built-in heat flux sensor and independent of properties or behavior of reaction mass. While unit does not require any calibration, it lets user make adjustments to actual chemistry and optimization of process parameters online.
