AirMotion Sciences, Inc.
Holliston, MA 01746
Jan 24, 2008 Measuring 9-15 ft in diameter, AltAir(TM) HVLS (High Volume - Low Speed) fans are used for cooling, heat de-stratification, and ventilation in large facilities. Products employ Variable Pitch Technology, Rotatair(TM) composite blades, and variable frequency drive capability. Adjusting blade pitch 0°-20° up or down, coupled with varying fan speed, promotes total control over air movement. When 3 or more fans are arranged in one array, they allow for complete air movement.

Mitsubishi Electric & Electronics - HVAC Advanced Products Div.
Lawrenceville, GA 30043
Jan 24, 2008 Including Models PLFY-NBMU and PLFY-NCMU, CITY MULTI® 4-way ceiling cassette units are adaptable to office cubicles and open spaces. Available in 6 capacities, PLFY-NBMU measures 33 x 33 in., and features long vanes for air distribution and auto wave air flow for even heat distribution in heating mode. Offered in 3 capacities, PLFY-NCMU measures 22 x 22 x 9½ in., and features 3 fan speeds and vane adjustment, including swing feature and one 4 in. ventilation air connection.

Kaeser Compressors, Inc.
Fredericksburg, VA 22404
Jan 23, 2008 Available for system capacities from 250-6,200 scfm, Kaeser Flow Controller (KFC) promotes effective storage by accumulating compressed air in receivers and only delivering air needed for production. Controller is designed for effective response to fluctuating demand and actively maintains constant system pressure downstream. Stored compressed air can also be used to satisfy air demand spikes without pressure drop at point of use.

Guyson Corporation of U.S.A.
Saratoga Springs, NY 12866
Jan 23, 2008 With 3 hp blower and non-ferrous 3,450 rpm impeller, cartridge-type Model D1000 extracts adjustable 1,000 cu-ft of air/min. Unit is fabricated in continuously welded 12-gauge steel plate with overall dimensions of 112 x 40 x 50 in. Two pleated paper cartridges each have filter area of 226 sq ft and provide average efficiency of 99.99% for particles of 0.5 micron or larger. Automatic pulse jet cleaning of filter cartridges is microprocessor controlled.

Omron Electronics LLC
Schaumburg, IL 60173
Jan 23, 2008 Measuring 19.6 x 15.6 x 15.6 mm, Model G5LA offers switching capacity of 10 A at 250 Vac/24 Vdc and 5 A at 250 Vac/24 Vdc on NO and NC contacts, respectively. With CTI of greater than or equal to 250, it conforms to VDE0435, UL508, and CSA 22.2 standards. Model G5LA-CF comes with Class F coil insulation and UL/CSA approved ambient operating temperature range of -40 to +85°C. Nominal coil power consumption is 360 mW for 5, 9, 12, and 24 Vdc coils and 480 mW for 48 Vdc coil.

VMAC Div., Mangonel Corp.
Nanaimo, BC V9X1R3
Jan 23, 2008 Delivering up to 40 cfm and 150 psi at dry weight of 150 lb, Model PREDATAIR40 above-deck hydraulic air compressor comes in 17 x 18 x 24 in. package. Rotary-screw compressor incorporates cold and soft start features, unload circuit, standby mode, service reminders, and system status display. Unit can operate at 100% duty cycle, and includes cooling system and remote LCD digital control box, system diagnostics, compressor/hydraulic temperature readings, and total system hours.

Conax Technologies
Buffalo, NY 14225
Jan 18, 2008 Compatible with data logging devices to track work area temperature history, wall-mount transmitter offers remote control capabilities and employs encapsulated, wire-wound 100 ohm platinum RTD with 0.00385 ohm/ohm/°C coefficient. Fixed range and programmable models are available, both of which can be field-mounted into standard single-gang electrical conduit box. Transmitter covers 40 to 80°F range and offers 4-20 mA output with accuracy of 0.1% of span (typ).

Phidgets, Inc.
Calgary, AB T2M3R7  Canada
Jan 17, 2008 Offering plug-and-play operation that only requires users to indicate operating system and desired computer language, 1124 - Precision Temperature Sensor measures ambient temperatures from -50 to +150°C with typical error of ±0.5°C at 25°C and ±0.75°C from 0 to +100°C. Maximum error is ±2°C at 0 to 100°C. While Phidgets can be programmed using API supported under Windows 2000/XP/Vista/CE, Mac OS X, and Linux, programs can be written in various languages.

Degree Controls Inc.
Milford, NH 03055
Jan 15, 2008 Used with engineered thermal solutions for electronic equipment, ATCA-compliant dual IPMI bus fan tray controller offers multiple filter clog and maintenance schemes as well as fan failure prediction and monitoring. Real-time selection of fan tray mode enables synchronized, closed-loop control of RPMs. Controller also offers real-time IPMI-based configuration of alarm thresholds and fan control curve set points as well as access to fan speeds, PWM values, and CLEI code data.

Omron Electronics LLC
Schaumburg, IL 60173
Jan 14, 2008 Model D6F-P MEMS Flow Sensor incorporates cyclone-type dust segregation system with bidirectional flow paths that generate cyclonic flows to separate dust particles from air using centrifugal forces. It offers flow range of +1.0 SLM, pressure range of +0.84 in. H₂O, and output signal range of analog 0.5-2.5 Vdc, with 0-0.5 Vdc indicating negative flow. Measuring 17 x 37 x 27 mm, unit is available in PCB mountable and connector models.

Flexaust Co., Inc., The
Warsaw, IN 46581
Jan 11, 2008 Designed to keep extreme temperatures inside, Flex-Vest® Insulated Hose features 1 in. fiberglass R-value=4 insulation sandwiched between double-ply silicone-coated fiberglass fabric inside layer, reinforced with spring steel wire helix. Outer layer is single-ply neoprene-coated polyester fabric, also reinforced with spring steel wire helix. Suited for industrial air movement and fume extraction, hose conforms to UL-94 and comes in 1-6 in. ID sizes and 12 ft lengths.

Watlow
St. Louis, MO 63146
Jan 11, 2008 THERMASLEEVE(TM) Hot Runner Nozzle Heater comes with rapid thermal response that allows heat to be created precisely where it is needed. Designed to have intimate contact with surface of nozzle which optimizes heat transfer, it features laser structuring to create customized temperature profile. Self-clamping electric heater can be installed and removed from nozzle with custom installation and removal tool, and accommodates thermocouple secured to external body of heater.

Emerson Process Management
Austin, TX 78754
Jan 08, 2008 Available in nominal ratings of 53, 70, 77, and 105 kW, upflow Liebert DS supports applications that require cooling from top of unit in data centers or telecommunications environments that do not have raised floor. Digital scroll compressors allow unit capacities to adapt to changing room conditions as small as ±1°F and ±1% RH. Providing diagnostic and maintenance support, Liebert iCOM(TM) control system enables multiple units to communicate and work together.

Sandvik Coromant Co.
Fair Lawn, NJ 07410
Jan 07, 2008 CoroTurn® HP combines with Coromant Capto® to harness capability of up to 1,100 psi in turning centers, vertical turning lathes, and multitask machines. Via turret or spindle, Capto coupling channels high-pressure coolant jet through small nozzles mounted close to insert cutting edge. Resulting velocity of coolant jet produces hydraulic wedge that lifts chip from material, reducing temperature and providing chip control.

Automation Products Group, Inc.
Logan, UT 84321
Jan 07, 2008 With microprocessor control, LPU-2428 Ultrasonic Level Sensors internally perform volume, flow, and totalization calculations. IP65-rated products provide 1-25 ft detection range and have built-in formulas for various flumes and weirs. Products can also be used to determine distance and level, and equation-based calculations are also possible. With output range-dependant response times from 0.6-3 sec, sensors deliver 0.1 in. resolution and accuracy of ±0.25% of detected range.

Aqua Products Co., Inc.
Newberry, SC 29108
Jan 04, 2008 Utilizing York® air source heat pump and R-410A refrigerant, Model RCS GREEN Reverse Cycle Chiller(TM) (RCC) can heat water to 115°F and cool water to 40°F. System can be sized to heating requirements of home. Available in 2-3 ton and 4-5 ton capacity models, chiller has optional APCHPL16 Aqua Solar Heat Pipe hot water collectors, which feature 16 glass vacuum tubes with high-intensity film and heat pipe to absorb solar energy.

Fargo Controls, Inc.
Eatontown, NJ 07724
Jan 02, 2008 Suited for use in automation and food processing machinery, High Temperature Inductive Proximity Sensors operate from -13 to +248°F and provide NPN or PNP NO output. Models are offered in 5 and 8 mm diameters and come totally sealed in cylindrical, threaded, stainless steel housing. Operating on 10-30 Vdc, CE- and RoHS-compliant products are shielded, have short circuit and reverse polarity protection, allow for flush mounting, and are protected to IP67.

BOC Edwards
Wilmington, MA 01887
Dec 26, 2007 ATLAS(TM) and TPU families of combustion exhaust management systems are available with idle mode that allows abatement systems to go into standby mode with reduced fuel and water consumption when exhaust is not flowing from attached process equipment. Available with 1-6 inlets, ATLAS systems provide exhaust management for CVD and etch processes (PECVD, HDPCVD, and WCVD), and are suited for treating exhaust streams containing fluorine (PFCs), SiH4, TEOS, WF6, and NH3.

Airius LLC
Longmont, CO 80501
Dec 26, 2007 Photohydroionization (PHI) AIRIUS Thermal Equalizer(TM) helps purify air and minimize airborne and surface bacteria, germs, viruses, fungi, spores, and mold in sizes that range from .001-10 microns. It helps to purify air with highly charged negative ions while dispersing them through compact air movement device that also equalizes air temperatures and humidity. System utilizes PHI-Cell(TM) to create aggressive, advanced oxidation atmosphere that can reduce airborne microbes.

Thermo Fisher Scientific
Newington, NH 03802
Dec 19, 2007 Able to be uncrated and installed by one person within minutes, NESLAB ThermoFlex 2500 can maintain temperatures from 5 to 40°C for continuous cooling in diverse applications and environments. Each chiller incorporates recirculation system with integrated funnel, full flow filtration, and visual fluid level indication. Air and fluid filters can be changed while equipment is running, and configurable options are available to tailor unit to specific applications.
