Time Delay Relay mounts in panel or socket.
January 2, 2002 -
AGASTAT 48K series has 8 timing modes including on delay, off delay, interval, one shot, repeat, cycle on/off delay, on/interval and accumulating on. It can time periods from 0.1 sec up to 10 hr. Rotary selector switch sets timing range, while adjustment knob provides fine-tuning. Repeat accuracy is 0.5% or ± 20 msec. Unit operates on 24-240 Vac, 50/60 Hz, or 24-125 Vdc. Relay contacts are rated up to 10 A resistive at 30 Vdc or 120/240 Vac.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Tyco Electronics Corp.
1050 Westlakes Dr.
Berwyn, PA, 19312
USA
Tyco Electronics Introduces Time Delay Relay
HARRISBURG, Pa., December 19 - Tyco Electronics recently introduced the AGASTAT 48K series time delay relay. The product is a universal device housed in a 1/16 DIN enclosure that can be mounted in a panel or socket. AGASTAT 48K time delay relays are capable of eight timing modes. The modes are: on delay, off delay, interval, one shot, repeat, cycle on/off delay, on/interval and accumulating on. These electronic timer relays have an extensive feature set and provide a high degree of accuracy making them suitable for many applications.
The 48K can time periods from 0.1 seconds up to 10 hours. A rotary selector switch sets the timing range. An adjustment knob provides fine-tuning of delay time via the unit's internal potentiometer. Repeat accuracy is rated at +/-0.5% +/-20 milliseconds and an overall accuracy of +/-I% +/-20 milliseconds. The unit operates on 24-240 VAC, 50/60 Hz or 24-125VDC. A double pole, double throw (2 16rm C) electromechanical relay performs output switching. The relay contacts are rated for up to 10 amps, resistive, at 30 VDC or 120/240 VAC. LED indicators display input power to the unit and power output from the relay.
|
|
|
|
|
|
|
|
