Test Modules allow testing/pre-emphasis of SerDes signals.
February 11, 2009 -
Designed to plug into VPX backplanes, 16-channel version of SerDes test modules test VPX switch and node cards and/or backplane channels without requiring external equipment or special test fixtures. They allow pre-emphasis tuning of VPX cards, and measure initial performance of VPX boards and fine-tune them. Plugging directly into backplane/chassis, modules help in characterization of signals and eliminate need for SMA connectors, cables, and capital-intensive measurement hardware.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Elma Bustronic
44350 Grimmer Blvd.
Fremont, CA, 94538
USA
Bustronic Offers New 16-Channel VPX SerDes Test Module
FREMONT, California, Jan. 30, 2009 - Elma Bustronic, a global manufacturer of electronic packaging products, has announced a new 16-channel version of its SerDes Test Modules for VPX systems. The modules allow testing and pre-emphasis of the SerDes signals to ensure signal performance of the system.
The 16-channel SerDes modules are designed to plug into VPX backplanes and directly test the channel compliance. They can be used to test VPX switch and node cards and/or the backplane channels without requiring external equipment or special test fixtures. The modules provide a quick and efficient look at the "vital signs" of the signals in the VPX system.
The Bustronic SerDes test modules also allow pre-emphasis tuning of VPX cards. The modules allow the user to measure the initial performance of the VPX boards and fine-tune them for optimum performance. Plugging directly into the backplane/chassis, the modules allow quick and easy characterization of the signals and eliminate the need for SMA connectors, cables, and capital-intensive measurement hardware. With a USB connection to a laptop or desktop computer, it is easy to create Eye Diagrams, measure Bit Error Rates (BER) and jitter, and more. Plus, the module kit includes software with a simple GUI interface. Within minutes, the user can plug the cards into the test chassis, connect the USB cable to a laptop, download the GUI software and begin measurements.
Bustronic can also provide SerDes test modules in other architectures and form factors, including ATCA, VXS, and MicroTCA.
The lead-time is 2-4 weeks ARO.
About ELMA BUSTRONIC:
Founded in 1989, Elma Bustronic specializes in the design and manufacture of high-performance backplanes. Elma Bustronic has a complete line of industry-standard backplanes, including CompactPCI, VME, VME64x, H.110 CT, VXI, VXS, and ATCA. Elma Bustronic's custom design service combines creative engineering, highly sophisticated computer simulation and modern design techniques to offer customized backplanes that meet the most specialized system requirements. A member of the ELMA Electronic group, Elma Bustronic is located in Fremont, California. Elma Bustronic is a member of PICMG(TM), VITA, and the StarFabric Trade Association and can be found on the World Wide Web at www.Bustronic.com.
|
|
|
|
|
|
|
|
