Temperature/Process Controller targets OEM machine builders.
June 19, 2009 -
Panel-mount E5CN-H controller offers universal inputs for temperature and analog processes as well as programmable 5-digit display with 0.01°C resolution. Unit has 60 ms sampling period with accuracy of ±0.1% of preset value for thermocouple/RTD inputs and ±0.1% full-scale for analog inputs. Preventive maintenance feature tracks load life of output relay, with ON/OFF cycle counter indicating when it nears end of operational life. Device measures 48 x 91 x 48 mm to fit 1/16 DIN panel cutouts.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Omron Electronics, LLC
1 Commerce Dr.
Schaumburg, IL, 60173
USA
Omron's E5CN-H 1/16 DIN Ultra Precise Temperature and Process Controllers Easily Adapt to OEM Machine Builders' Needs with a Single Model
SCHAUMBURG, IL (June 2009) - Omron Electronics LLC (www.omron247.com) has extended its line of proven E5CN series 1/16 DIN size temperature and process controllers with advanced E5CN-H models that provide OEM machine builders with high-speed response, higher resolution and accuracy than standard models, and a wider range for performance customization to meet project requirements, including logic operations and preventive maintenance functions. The advanced functions, including password protected settings and customizable menus, are accessed via CX-Thermo software to ensure the highest level of security. The compact panel-mount controller's universal inputs for temperature and analog processes, selection of 13 alarm types and 3-color changing display to indicate status enable machine builders to use one model to satisfy the needs of many projects and lower design, purchasing, programming and stocking costs.
The E5CN-H models offer a fast 60 ms sampling period which allows more precise heater control in rapidly changing, disturbance-sensitive applications. With accuracy of ±0.1% of preset value (PV) for thermocouple and RTD inputs and ±0.1% full scale for analog inputs, the 2-PID control delivers exact control and stability with fast reaction speed. Time saving auto-tuning in E5CN series is considered one
The 5-digit display with 0.01 degrees Celsius display resolution on E5CN-H models shows both PV and SV at a glance and can be preprogrammed so that it changes color (red to green to orange) in response to an alarm, a preset value, or when values vary outside a preset threshold. In a packaging application, the display change can alert plant floor staff that a heater has burned out in a form/fill/seal machine and detect a bad sealing situation before it turns into a high waste situation. The display can also be set to alternate between PV/SV-status and Temperature Controller status (auto/manual, RUN/STOP, and alarms).
The E5CN-H provides flexible contact outputs with logic operations (AND, OR and time delays) that enable OEMs to build simple logic and timing programs. The 8 logic registers offer a robust capability that proves useful with pumps, where a minimum ON time is required.
A unique preventive maintenance feature built into the E5CN-H controller tracks the load life of the output relay. The ON/OFF cycle counter can be set via software to alert staff when the relay nears the end of its operational life enabling planned replacement instead unexpected failure.
Space-saving E5CN-H temperature and process controllers measure 48 H x 48 W x 91 D mm to fit 1/16 DIN panel cutouts. Controller and Option Boards for heater burnout detection, serial communication, event inputs, a second control output, and transfer analog output are available from stock. CX-Thermo Support Software provides access to expanded functionality and security settings, and enables OEMs to set multiple units with the same program and monitor operations of multiple units for debugging and plant-floor diagnostics.
For further information, contact: Omron Electronics LLC, 1 Commerce Drive, Schaumburg, IL 60173. Tel.: 866-88-OMRON. Fax: 847-843-8081. Internet: www.omron247.com.
Omron Electronics LLC is a leading global manufacturer of industrial automation products focused on sensing and control technologies. We serve OEM machine builders and end users with a wide range of products that integrate easily into complete automation solutions, offer simple connectivity, and are backed by solid support services. Our extensive product groups include programmable controllers, servo motors and drives, operator interfaces, temperature controllers, sensors, inspection and machine vision systems, RFID track and trace systems, and software. Omron Electronics LLC is the Americas subsidiary of Omron Corporation, a $7 billion global leading supplier of reliable, advanced electronics and control system components and services celebrating 75 years of success.
