TVS Diodes provide maximum ESD protection.
September 14, 2010 -
Measuring 0.62 x 0.32 x 0.28 mm, SP1005 Series offers up to ±30 kV ESD protection and 10 A of surge protection with only 0.7 W of dynamic resistance, while Series SP1007 can withstand up to ±8 kV ESD, which protects up to max level of IEC61000-4-2 international standard. Both discrete bidirectional devices are suitable for designs where board space is severely limited including mobile phones, camcorders, PDAs, digital cameras, PNDs, and POS terminals.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Littelfuse, Inc.
800 E. Northwest Hwy.
Des Plaines, IL, 60016
USA
Latest Additions to the SPA(TM) Portfolio
Latest additions to the SPA(TM) portfolio provide best-in-class ESD protection by offering the lowest dynamic resistance in the industry's smallest available footprint
CHICAGO, IL, - Littelfuse, Inc. (NASDAQ/NGS:LFUS) announced the introduction of the SP1005 and SP1007 Series today. Both series are discrete bidirectional TVS diodes for ESD protection measuring only 0.62x0.32x0.28mm.
The SP1005 (30pF @ 0V) offers up to ±30kV ESD protection and 10A (tP=8/20µs) of surge protection with only 0.7W of dynamic resistance, providing best-in-class clamping performance. The SP1007 (3.5pF @ 2.5V) can withstand up to ±8kV ESD, which protects up to the maximum level of the IEC61000-4-2 international standard.
Both devices are particularly suitable for designs where board space is severely limited including applications such as mobile phones, smart phones, camcorders, PDAs, digital cameras, MP3/PMPs, portable navigation devices, portable medical devices, and point-of-sale terminals. Furthermore, the SP1005 offers best-in-class ESD clamping due to its low dynamic resistance of only 0.7W. For more information on dynamic resistance and how to select an ESD device please see www.littelfuse.com/data/en/App...
The new SP1005 and SP1007 Series are RoHS compliant and comply with the following standards:
SP1005:
ESD, IEC61000-4-2, ±30kV (contact), ±30kV (air)
Lightning, IEC61000-4-5, 10A (tP=8/20µs)
EFT, IEC61000-4-4, 40A (tP=5/50ns)
SP1007:
ESD, IEC61000-4-2, ±8kV (contact), ±15kV (air)
Lightning, IEC61000-4-5, 2A (tP=8/20µs)
EFT, IEC61000-4-4, 40A (tP=5/50ns)
Availability
SP1005 and SP1007 Series samples are available now for order and sample request through authorized Littelfuse distributors worldwide, 12 weeks ARO, in 10,000-quantity reel package.
For More Information
For more information about the SP1005 and SP1007 Series, please visit the Littelfuse website at www.littelfuse.com or contact your local Littelfuse Technical Support expert.
About Littelfuse
Littelfuse is the worldwide leader in circuit protection, offering the industry's broadest and deepest portfolio of circuit protection products and solutions. Backed by industry-leading technical support, design and manufacturing expertise Littelfuse products are vital components in virtually every product that uses electrical energy, including portable and consumer electronics, automobiles, industrial equipment and telecom/datacom circuits. In addition to its Chicago, Illinois, world headquarters, Littelfuse has over 20 sales, distribution, manufacturing and engineering facilities in the Americas, Europe and Asia. Technologies offered by Littelfuse include Fuses; Gas Discharge Tubes (GDTs); Positive Temperature Coefficient Devices (PTCs); Protection Relays; PulseGuard® ESD Suppressors; SIDACtor® Devices; Silicon Protection Arrays(SPA(TM)); Switching Thyristors; TVS Diodes and Varistors.
