Single-Channel High-Side Drivers are automotive-qualified.
September 15, 2008 -
Offered in 8-lead SOIC package, high-speed power MOSFET and IGBT drivers AUIRS2123S/AUIRS2124S are qualified to AEC-Q100 standards and offer 10-20 V gate drive supply. High-pulse current buffer stage is designed for minimum driver cross-conduction, while floating channel can drive N-channel power MOSFETs or IGBTs in high-side configuration operating up to 600 V. AUIRS2123S output signals are in phase with input signal, while AUIRS2124S output signals are out of phase with input signal.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
International Rectifier Corp.
233 Kansas St.
El Segundo, CA, 90245
USA
IR Introduces Rugged, Reliable Automotive-Qualified 600V ICs
EL SEGUNDO, Calif. - International Rectifier, IR® (NYSE: IRF), a world leader in power management technology, today introduced the AUIRS212xS family of rugged 600V, single channel high-side driver ICs for low-, mid-, and high-voltage automotive applications including general purpose automotive drives, high-voltage actuators and fuel-efficient direct injection systems.
Qualified to AEC-Q100 standards, the AUIRS2123S and AUIRS2124S high speed power MOSFET and IGBT drivers offer a gate drive supply range from 10V to 20V. The output drivers feature a high-pulse current buffer stage designed for minimum driver cross-conduction while the floating channel can be used to drive N-channel power MOSFETs or IGBTs in the high-side configuration operating up to 600V. Both devices feature negative voltage spike (Vs) immunity to protect the system against catastrophic events during high-current switching and short circuit conditions.
"Designed specifically for automotive applications, the new ICs use a proprietary latch immune CMOS technology featuring exceptional negative Vs immunity to deliver the ruggedness and reliability essential for harsh environments and automotive under-the-hood applications," said Henning Hauenstein, vice president of IR's automotive products.
The AUIRS2123S features output signals in phase with the input signal while the AUIRS2124S features output signals out of phase with the input signal. Both devices provide under-voltage lockout and CMOS Schmitt-triggered inputs with pull-down.
The new ICs utilize IR's advanced high-voltage IC process which incorporates next-generation high-voltage level-shifting and termination technology to deliver superior electrical over-stress protection and higher field reliability.
More information is available at the International Rectifier website at http://www.irf.com/whats-new/nr080904.html
Availability and Pricing
Available in an 8-lead SOIC package, pricing for the AUIRS212xS begins at US$0.72 each in quantities of 100,000 units. Production quantities are available immediately. The automotive- qualified devices are lead-free and RoHS compliant. Prices are subject to change.
About International Rectifier
International Rectifier (NYSE:IRF) is a world leader in power management technology. IR's analog- and mixed-signal ICs, advanced circuit devices, integrated power systems, and components enable high-performance computing and reduce energy waste from motors, the world's single largest consumer of electricity. Leading manufacturers of computers, energy-efficient appliances, lighting, automobiles, satellites, aircraft, and defense systems rely on IR's power-management benchmarks to power their next generation products. For more information, go to www.irf.com.
Trademark Notice
IR® is a registered trademark of International Rectifier Corporation. All other product names noted herein may be trademarks of their respective holders.
For more information, contact Graham Robertson, grobert1@irf.com 310-726-8512.
|
|
|
|
|
|
|
|
