Screw Conveyor to include helical-bevel gear products.
June 27, 2012 -
Screw conveyor package is available with right-angle bevel products for installation of gear boxes in confined spaces. While 3-hole tapered CEMA drive shaft aids mounting/removal, adjustable flange allows for multiple bolt patterns. Design uses direct coupled gearmotor or NEMA C-face input, eliminating need for separate V belt. Depending on model, NORD helical-bevel screw conveyor drive produces up to 30 hp and torque to 42,480 lb-in. and operates on 95% or greater efficiency.
Original Press release
Getriebebau-Nord GmbH + Co.
Rudolf-Diesel-Straße 1
, , -
Germany
NORD Gear Corp. Announces Expansion of Screw Conveyor Package to Include Helical-Bevel Gear Products
Waunakee, WI - NORD announces the addition of the helical-bevel gear series to its successful high-performance screw conveyor package. The newly designed right angle bevel products allow you to install gear boxes in confined spaces while maintaining the simplicity, reliability and efficiency of NORD's traditional gearmotors and speed reducers.
Standard Features
The right angle bevel series is more compact compared to the existing parallel helical screw conveyor package. Its right-angle design is compatible with standard CEMA mounting. The three-hole tapered CEMA drive shaft offers easy mounting and removal. Its adjustable flange allows for multiple bolt patterns. It features an optimized sealing system that includes dual Viton® lip seals, grease impregnated packing seal, dual gap seals, material evacuation ports, a shaft material ditch and Quadrilip(TM) sealing.
The NORD right angle bevel series uses either the direct coupled gearmotor or NEMA C-face input design, making it extremely efficient. The simplified design eliminates the need for a separate V belt. Belted systems are costly and require additional parts, lowering drive performance. The NORD helical-bevel design provides optimal performance and decreases maintenance time and cost.
NORD helical-bevel screw conveyor drives produce torque levels ranging up to 42480 lb-in and powers up to 30 hp, depending on model. Each model operates on a 95 percent efficiency level or greater, maximizing productivity.
All NORD models include the UNICASE(TM) design. Speed reducer housings are constructed of one solid cast-iron piece containing the bearings and seal seats, which eliminates the need for splits or bolt-on carriers that can weaken the housing and allow oil leaks. This cast-iron design can withstand weight from the heaviest loads.
All NORD products are specially designed for protection against the harshest environmental conditions and feature:
-The AUTOVENT(TM) breather regulates airflow and controls pressure inside the gear case. It also protects bearings by blocking out environmental materials like water, dust and corrosives.
-Stainless steel protective paint protects against corrosion and increases durability. The internal housing is coated with a high-performance synthetic primer to lock in any residual casting sand and seal any imperfections.
For more information about the NORD Gear right angle bevel series or the parallel helical SCP screw conveyor package, contact:
Barbara Houdek
NORD Gear Corporation
A member of the NORD Drivesystem Group
800 NORD Drive, P.O. Box 367
Waunakee, WI 53597
(888) 314-6673 or (608) 849-7300
Fax (800) 373-6673
www.nord.com
Company background
NORD was founded in 1965 to develop, produce, and market drive technology. As an industry leader ranking # 2 in the US & Canada and # 2 as the Global Leader, NORD reaches nearly all markets. With 2800 employees and 35 assembly factories worldwide, sales and support is available in 60+ countries. This ensures short delivery times and services close to you. NORD supplies application-specific concepts and solutions which include but are not limited to energy-saving drives. NORD provides a wide range of products to meet your needs with gearboxes ranging in torque ratings from 8.5 lb-in to 1, 770, 000 lb-in and electric motors rating in power from 1/6 HP to 250 HP. In addition, the product line consists of high performance AC Vector Drives and AC Drives for panel mount or distributed motor mount.
