PWM Clock/Silicon Oscillator covers 3.81 Hz to 1 MHz range.
September 27, 2010 -
Available in ThinSOT(TM) and 2 x 3 mm DFN packages, TimerBlox(TM) LTC6992 offers PWM capability for output frequencies from 3.81 Hz to 1 MHz. Frequency is programmed using 1-3 resistors, with frequency error less than 1.7%, and can be dynamically controlled via separate control voltage. Also, output pulse width is controlled via analog signal from 0-1 V. Available in 4 versions with 0% or 5% min and 95% or 100% max duty cycle limits, clock offers glitch-free, first cycle accurate startup.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Linear Technology
17000 Dallas Pkwy., Suite 200
Dallas, TX, 75248
USA
Simple, Accurate & Tiny PWM Clock Covers 3.81Hz to 1MHz
MILPITAS, CA - Linear Technology announces the LTC6992 silicon oscillator, the latest member of the TimerBlox(TM) family of silicon timing devices. The LTC6992 offers simple and accurate pulse width modulation (PWM) capability for output frequencies from 3.81Hz to 1MHz. The device's frequency is programmed using 1 to 3 resistors, with guaranteed frequency error less than 1.7%. In addition, the frequency can be dynamically controlled via a separate control voltage. The output pulse width (duty cycle) is simply controlled with an analog signal from 0 to 1V. The LTC6992 offers glitch-free, first cycle accurate startup within 500us of power on.
Four versions of the LTC6992 are available, each offering a unique combination of minimum/maximum duty cycle limits. The minimum duty cycle can be 0% or 5%, and the maximum duty cycle limit can be 95% or 100%. The 5% and 95% duty cycle limits ensure that the output will continue to toggle, irrespective of the control voltage, for applications unable to tolerate a DC control signal. The LTC6992 is well suited for heater control, PWM servo loops, LED dimming, signal isolation and other duty cycle control applications.
The LTC6992 is part of the TimerBlox family of versatile silicon timing devices in which an accurate programmable oscillator is combined with precision circuitry and logic. No capacitors, no crystals, no microcontroller and no programming are required. TimerBlox devices are solid state and can be operated under high acceleration, vibration and temperature extremes. They offer higher accuracy, stability and lower power consumption than typical resistor/capacitor-based oscillators. The 20mA source and sink capability enables direct drive of opto-isolators and transformers for electrical isolation. Fully specified over the temperature range of -40°C to 125°C, the TimerBlox parts are suitable for demanding automotive and industrial environments where many oscillators and microcontrollers are unable to operate. The small SOT23 footprint allows each timing device to be placed at the point of use, without routing signals over long distances, and provides an ideal timer for space-limited applications such as handheld and portable devices.
"With the LTC6992, generating a PWM signal is extremely easy," says Doug LaPorte, Design Manager for Linear Technology. "No microcontroller and no programming is necessary."
The LTC6992 is now available, priced starting at $1.55 each in 1,000-piece quantities. For more information, visit www.linear.com/6992.
Summary of Features: LTC6992
Internal Oscillator
- No Crystal
- No Timing Caps
Simple Set-up Using 1 to 3 Resistors
- Frequency Range: 3.81Hz to 1MHz
- <1.7% Max Frequency Error
Four Available Options Define Duty Cycle Limits
- Minimum Duty Cycle at 0% or 5%
- Maximum Duty Cycle at 95% or 100%
PWM Duty Cycle Error < 3.7% Maximum
Frequency Modulation (VCO) Capability
2.25V to 5.5V Single Supply
115uA Supply Current at 100kHz
CMOS Output Driver Sources/Sinks 20mA
-40°C to 125°C Operating Temperature Range
Low Profile ThinSOTTM & 2mm x 3mm DFN Packaging Available
