PIN Diodes suit commercial and military applications.
November 15, 2005 -
Featuring standard 0402 footprint, packageless Surmount Series MA4SPS42x and MA4PD-042005 are manufactured using Vertical Etch Technology, which facilitates heat transfer through silicon cylinder. Offering peak power of 500 W, 100 µm I-region Series MA4SPS42x features 1 µS pulse width, 0.001 duty cycle, and average power of 10 W. With peak power of 50 W, 5 µm I-region Series MA4PD-042005 provides 1 µS pulse width, 0.001 duty cycle, and up to 25 W average power.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
M/A-COM, Inc.
1011 Pawtucket Blvd.
Lowell, MA, 01853
USA
M/A-COM Announces Higher Power Additions to Surmount Packageless Pin Diode Family
Improved Handling of Average Incident Power Designed for Commercial and Military Control Circuit Applications
LOWELL, Mass. - Oct. 11, 2005 - M/A-COM, a business unit of Tyco Electronics and a leading provider of wireless radio frequency (RF), microwave and millimeter wave components, today announced three additions to its existing line of packageless Surmount PIN diodes. The MA4SPS421, MA4SPS422 series devices and MA4PD-042005 series diodes provide superior power performance for future platform mobile radio and military control circuit switch and attenuator applications for the 1 MHz to 18 GHz operating range.
The compact MA4SPS42x and MA4PD-042005 series devices feature the standard "0402" (40 x 20 mils sq.) style footprint, consistent with the current family of Surmount PIN diodes, including the MA4SPS302, MA4SPS402 and MA4SPS502. The products are manufactured using a "Vertical Etch Technology," which provides lower parasitic CP and LS, while significantly improving the device heat transfer through the silicon cylinder. These superior-performing Surmount devices present circuit designers with an improved design solution over plastic packaged diodes. The MA4SPS42x, 100 um I-region series, offer high peak power (500 W, 1 uS pulse width, 0.001 duty cycle) and high average power (10 W) performance, where the 5 um I-region MA4PD-042005 series offer 50 W peak power, 1 uS pulse width, 0.001 duty cycle and up to 25 W average power performance. They function best when deployed in high signal microwave switching and attenuation control circuits.
The entire MA4SPS and MA4PD-042005 Surmount PIN diode series are manufactured using M/A-COM's proprietary HMIC silicon glass process to enable the integration of silicon PIN diodes with a low dispersion, low-loss glass medium to produce either two terminal or multi-port devices. This process produces exceptional device parametric reliability and repeatability.
These "packageless" devices provide significant electrical and mechanical performance advantages over their plastic counterparts. The "0402" style outline makes them compatible with existing surface mount manufacturing techniques and ideal for very large scale component integration.
Pricing and Availability
The MA4SPS42x and MA4PD-042005 series are available from stock and are priced at $1.60 each in quantities of 100,000. Contact M/A-COM's domestic and international sales channels for price and delivery quotes. Data sheets and supporting technical documents are available online at www.macom.com.
M/A-COM, Inc., a business unit of Tyco Electronics, is an established industry leader in the design, development and manufacture of radio frequency (RF), microwave and millimeter wave semiconductors, components and technologies for the wireless telecommunications, automotive, aerospace and military industries. Holding hundreds of patents in the field, M/A-COM is internationally known as an innovator and integrator whose technologies are found in some of today's most advanced signal intelligence and defense systems, as well as in leading automotive navigation, safety, and communications solutions. M/A-COM is also a major supplier of critical communications systems and equipment for public safety, utility, federal and select commercial markets. Headquartered in Lowell, MA, M/A-COM has offices and manufacturing facilities worldwide. Information about M/A-COM can be found on the Web at http://www.macom.com, a complete, updated listing of all of M/A-COM's RoHS compliant parts is available on the Web at http://www.macom.com/rohs.
Tyco Electronics, a business segment of Tyco International Ltd., is the world's largest passive electronic components manufacturer; a world leader in cutting-edge wireless, active fiber optic and complete power systems technologies; and a provider of premise wiring components and systems. Tyco Electronics provides advanced technology products from over forty well-known and respected brands, including Agastat, Alcoswitch, AMP, AMP NETCONNECT, Buchanan, CII, CoEv, Critchley, Elcon, Elo TouchSystems, M/A-COM, Madison Cable, OEG, Potter & Brumfield, Raychem, Schrack and Simel. For more information, visit www.tycoelectronics.com.
o M/A-COM, Tyco, HMIC and SURMOUNT are trademarks.
o Other products, logos and Company names mentioned herein may be trademarks of their respective owners.
