PCB Terminal Strips handle high currents.
June 19, 2002 -
Compact 745 Series have current rating of 50 A, are available with pin spacings of 15 and 20 mm, and accommodate wire from #24 to #6 AWG. Four solder pins ensure terminal strips fit securely and guarantee safe and efficient current distribution. Jumpers can be used to loop through potentials or connect current circuits in parallel. Separate test slots can be accessed, even with wires connected.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
WAGO Corp.
N120 W19129 Freistadt Rd.
Germantown, WI, 53022
USA
Higher Current PCB Terminal Strips Retain Compact Design
Germantown, WI, May 2002 -The WAGO PCB terminal strips, 745 Series, feature a space-saving design and an increased current rating of 50 A. The 745 Series is available with a pin spacing of 15 mm and 20 mm, and is designed for use with wire gauges from #24 to #6 AWG. Four solder pins ensure the terminal strips fit securely and guarantee safe and efficient current distribution.
Additional benefits of the compact 745 Series include the convenience of using jumpers to loop through potentials or connect current circuits in parallel. Separate test slots can be accessed, even with the wires connected. Fixing flanges for horizontal and vertical fixing are also available.
WAGO is the worldwide leader in spring pressure termination technology. Since it was formed in 1951, WAGO's core business has been the design, manufacture and marketing of an increasingly wide range of highly innovative terminal blocks and connectors featuring the company's unique Cage-Clamp connection technology. WAGO also specializes in DIN rail mounted fieldbus independent I/O systems, custom electronics and factory automation products. For more information, call Inside Sales at 1-800-DIN-RAIL, or visit www.wago.com.
|
|
|
|
|
|
|
|
