Non-Contact Sensor measures turbine vane segments.
January 12, 2009 -
Able to scan polished or machined surfaces without any coating, MAXOS XR (Extended Range) features concentrated light spot that can measure at standoff of 8 in. with angle of incidence to surface of as little as 15°. It can scan between individual vanes and measure complete cross-sections of each blade segment at all required section heights. Another unique feature for measurement of nozzle segments is ability to measure position and depth of slot seals.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
NVision, Inc.
112 Welford Lane, Suite 126
Southlake, TX, 76092
USA
NVision Announces the MAXOS XR for Vane Segment Measurement
(January 8, 2009) -- NVision is excited to announce the launch of the MAXOS XR (Extended Range), which expands the measurement capabilities for multiple vane applications. The XR augments the MAXOS multi-axis optical CMM product line, already the industry standard for non-contact measurement of turbine blades due to its speed, accuracy and ability to scan polished or machined surfaces without any coating.
Nozzle or vane segments of a turbine stator are normally impossible to inspect using optical measurement and notoriously time-consuming to inspect using conventional CMM technology. The problem is the limited space available between individual blades and the resulting angles of approach. Inspection by conventional CMM requires long custom-shaped touch probes that need regular recalibration and is often inaccurate due to ball-offset or cosine error.
The MAXOS XR addresses these problems. The sensor's concentrated light spot can measure at a standoff of 8 inches with an angle of incidence to the surface of as little as 15 degrees. With this technical breakthrough, the MAXOS XR can scan between individual vanes and measure complete cross-sections of each blade segment at all required section heights.
Another unique feature for the measurement of nozzle segments is the ability of the MAXOS XR to measure the position and depth of slot seals, a notoriously difficult operation to automate.
The MAXOS is one of the most widely used non-contact blade measurement systems in the aerospace and industrial power generation industries. The system is used by companies such as GE, Alstom, Siemens, and Centrax.
For more information about the MAXOS XR, contact NVision at:
o28287 Beck Rd., Suite 3D, Wixom, MI 48393. Ph: 248.468.2525, Fax: 248.468.2528
o112 Welford Lane, Suite 126, Southlake, TX 76092. Ph: 817.749.0050, Fax: 817.749.0052
E-mail: sales@nvision3d.com. Visit NVision's Web site at www.nvision3d.com.
|
|
|
|
|
|
|
|
