Multiway Coax Connectors have up to 40 GHz of VSWR.
May 21, 2009 -
With max overall dia of 0.133 in. fitted into low-profile metalized housing, high frequency Micro-D Coax Connectors have constant airline impedance interface of 50 W. Insert arrangements are available in 2, 4, 6, 8 and 10 way coax assemblies as well as mixed signal, power, coax, and high speed twinax for hybrid arrangements. Products come with locking post mechanisms or blind-mate hardware attachment, and have operating frequency range between 10-40 GHz.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Sabritec
17550 Gillette Ave.
Irvine, CA, 92614
USA
Sabritec Introduces New Low VSWR Multiway Coax Connectors
Sabritec, a custom connecting devices manufacturer, today announces the launch of their new High Frequency Micro-D Coax Connectors (MDHC) with low VSWR up to 40 GHz (typ). These connectors have a constant 50 ohm airline impedance interface and are 30% smaller than their SCX coaxial connectors.
The ultra-miniauture MDHC contacts are compact in size allowing multiple high density connections in a Micro-D style shell for applications where tight space and weight savings are critical. These contacts have a maximum overall diameter of 0.133" fitted into a low-profile metalized housing. MDHC coaxial contacts are a drop in replacement to Sabritec's MDCX RF contacts with an increased frequency range from10 GHz to 40 GHz.
MDHC Connectors are also available with locking post mechanisms or blind-mate hardware attachment. Insert arrangements are available in 2, 4, 6, 8 and 10 way coax assemblies as well as mixed signal, power, coax, and high speed twinax for hybrid arrangements.
Specification sheet available for download at: http://sabritec.com/Spec Sheets/MDHC.pdf
About Sabritec
Sabritec is an ISO 9001 certified company that specializes in the design and manufacture of coax, triax, filtered, and high speed interconnects (Fibre Channel, Ethernet, Firewire), fiber optic connectors, contacts, and cable assemblies. Sabritec is completely vertically integrated, creating high quality precision interconnect products from initial concept, design and development, through production and acceptance testing. Sabritec is part of Smiths Interconnect.
About Smiths Interconnect
Smiths Interconnect, part of the global technology business Smiths Group, designs and manufactures specialized electronic and radio frequency products that connect, protect and control critical systems for the wireless telecommunications, aerospace, defense, space and medical markets. For further information visit www.smithsinterconnect.com
About Smiths Group
Smiths is a global technology business listed on the London Stock Exchange. A world leader in the practical application of advanced technologies, Smiths Group delivers products and services for the threat & contraband detection, energy, medical devices, communications and engineered components markets worldwide. Our products and services make the world safer, healthier and more productive. Smiths Group employs more than 20,000 people in over 50 countries. For more information visit www.smiths.com
