Low-Power Op Amps feature self-correcting architecture.
July 15, 2008 -
Suited for portable, battery-powered instrumentation devices, MCP6V01/2/3 auto-zero op amps have operating voltage range of 1.8-5.5 V and quiescent current of 300 µA. Rail-to-rail I/O structure, combined with self-correcting architecture and input offset voltage of 2 µV max, provide flexibility with regards to gain control and dynamic range. All models are supplied in 8-pin SOIC packages, with MCP6V02 also offered in 4 x 4 mm DFN package.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Microchip Technology, Inc.
2355 W. Chandler Blvd.
Chandler, AZ, 85224 6199
USA
Microchip Technology Introduces Low-Power, Auto-Zero Operational Amplifiers (Op Amps)
Op Amps Provide Ultra High Precision and Rail-to-Rail Operation
CHANDLER, Ariz., June 23, 2008 [NASDAQ: MCHP] - Microchip Technology Inc., a leading provider of microcontroller and analog semiconductors, today announced the HTUMCP6V01/2/3UTH (MCP6V0X) auto-zero operational amplifiers (op amps). The low-power op amps feature a unique self-correcting architecture that enables ultra high precision, with an input offset voltage of just 2 micro Volts (µV) maximum. They also feature high common-mode rejection, rail-to-rail input/output and low quiescent current; making them ideal for portable, battery-powered instrumentation devices, such as those used in the UindustrialU and UmedicalU markets.
With their low operating-voltage range of 1.8V to 5.5V and low typical quiescent current of just 300 microamperes (µA), the MCP6V0X op amps can run off two 1.5V cells with full battery utilization. The devices feature a self-correcting architecture that results in fewer errors, especially at higher gains. Additionally, their rail-to-rail input/output structure enables greater dynamic range. The combined result of these features is better system performance at all operating voltages.
"Microchip continues to leverage its low-power CMOS technology to provide yet another industry-leading op amp family," said Bryan Liddiard, vice president of marketing with Microchip's Analog and Interface Products Division. "The MCP6V0X amplifiers extend our op amp portfolio into the ultra high-precision marketplace, and provide critical intellectual property for continued growth in this area."
Kevin Tretter, senior product marketing engineer with Microchip's Analog and Interface Products Division, continued, "The MCP6V0X op amps' extremely low offset and rail-to-rail performance provide tremendous flexibility, with regard to gain control and dynamic range. We expect these devices to enable new markets in instrumentation."
Applications requiring low power consumption, low-voltage operation, ultra high precision and low drift can benefit from the performance and features offered by the MCP6V0X op amps. Examples include battery-powered devices and instrumentation used in UmedicalU applications (e.g. sensor calibration for defibrillators and CT scanners); as well as UindustrialU applications (e.g. high-precision temperature sensing and DC offset correction).
Development Support
Like all Microchip op amps, the MCP6V0X family is supported by the FilterLabP®P Analog Filtering Software Tool and the Mindi(TM) Online Simulator Tool. Available for free from Microchip's Web site at HTUwww.microchip.com/filterlabUTH, the FilterLab analog filtering software tool provides full schematic diagrams of the filter circuit with component values, and displays the frequency responses. Also available for free, the interactive Mindi simulator tool (HTUwww.microchip.com/mindiUTH) enables designers to quickly generate circuit diagrams, simulate circuits and specify passive components for a variety of power and battery-charger applications. Circuits developed using the Mindi tool can be downloaded to a PC or workstation, and are often ported directly into system diagrams.
Device Packaging, Pricing & Availability
The MCP6V0X op amps are available for sampling and purchase today. Samples can be ordered at HTUhttp://sample.microchip.comUTH, and volume production orders can be placed at HTUmicrochipdirect.comUTH. All of the new op amps are available in 8-pin SOIC packages, with the MCP6V02 also offered in a 4 mm x 4 mm DFN package. The MCP6V01 is priced at $1.26 each in 10,000-unit quantities; the MCP6V02 at $1.92 each in 10,000-unit quantities; and the MCP6V03 at $1.31 each in 10,000-unit quantities.
For further information, contact any Microchip sales representative or authorized worldwide distributor, or visit Microchip's Web site at HTUwww.microchip.com/MCP6V0XUTH.
