LCD Controller features 16 bit ITU 605 bus connector.
March 14, 2008 -
Model HE-1920 provides analog and digital connections (PC, DVI, and Video Interface) for TFT LCD panels up to WUXGA resolution of 1,920 x 1,200 pixels. Featuring wide tolerance power supplies (12 Vdc ±25%), locking connectors, and low-mass tantalum capacitors, it offers tolerance to shock and vibration. Measuring 7 x 4.74 in., interface controller has Mil-spec silicon resin conformal coatings, operating temperature range of -40 to +80șC, and calculated MTBF in excess of 100K hr.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Digital View, Inc.
18440 Technology Drive, Building 130
Morgan Hill, CA, 95037
USA
New Digital View High-Performance LCD Controller Is Ideal for Harsh Environment Monitor & Broadcast Video Applications
Morgan Hill, CA, March 5, 2008 - Digital View's new HE-1920 is a fully buffered multi-sync interface controller that provides analog and digital connections for large format, high-definition TFT LCDs plus wide operating temperature and voltage ranges, heightened shock and vibration tolerance, and conformal coating for extreme environment applications.
The HE-1920 is the latest in Digital View's new HE Series of COTS LCD controllers designed to comply with the strict standards required for the harsh environments encountered in military and rugged industrial applications. Designed to aid manufacturers building hardened panel display systems requiring advanced capabilities such as high resolution and high-definition, the HE-1920 features wide tolerance power supplies (12 VDC ± 25%), locking connectors and low-mass tantalum capacitors for maximum tolerance to shock and vibration, Mil-spec silicon resin conformal coatings, a laboratory-certified operating temperature range of - 40șC to +80șC, and calculated MTBF in excess of 100 K hours, with full RoHS compliance.
A fully buffered multi-sync interface controller, the HE-1920 provides analog and digital connections - PC, DVI & Video Interface - for a wide range of TFT LCD panels up to WUXGA resolution (1920 x 1200 pixels). It features full screen image expansion of lower resolutions, image flip and invert functions, and onscreen PIP functions.
"The HE-1920, offers an inexpensive, off-the shelf COTS controller that supports high resolution formats in military or harsh environment industrial applications," said Neil Wood, Director of Product Marketing for Digital View's Display Electronics division.
The HE-1920 also features a 16 bit ITU 605 bus connector designed to permit developers to independently create proprietary hardware interfaces for the controller. The interfaces provide software managed selection pins to manage multiple input configurations. Typical examples include optical inputs, additional ports, HD-SDI, etc.
The HE-1920 measures a compact 179 mm x 120.4 mm (7" x 4.74"), and comes with a full
3-year warranty.
The HE-1920 is priced at $269.00 U.S. each in 1,000-unit quantities. It is available directly from Digital View and through the company's distribution network. Delivery is off-the-shelf.
About Digital View
Established in 1995, Digital View Group (www.digitalview.com) is one of the world's foremost suppliers of advanced interface solutions for the LCD display market and a world leader in the supply of retail video promotion and digital signage solutions. The company also develops display electronics products and services used in demanding specialized OEM applications. Digital View has sales offices worldwide in Morgan Hill, CA, USA, London, England, and Hong Kong.
