Drive Components suit cleanroom assembly operations.
January 6, 2009 -
Available in outside diameters from 16-35 mm and inside diameters from 6-20 mm, Magnetic Transmission Drive Components operate on principle of attractive force, making them suited for applications where non-contacting components result in ultra low dust generation. Type MDQ allows perpendicular alignment, while Type MDY allows parallel alignment. All components are housed in 5056 aluminum with gas emission prevention treatment.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Misumi USA
1105 Remington Rd., Suite B
Schaumburg, IL, 60173
USA
Misumi Introduces Magnetic Transmission Drive Components
Misumi USA, Inc., a subsidiary of Misumi Corporation, part of Misumi Group, Inc. (TYO:9962), announces a new line of magnetic transmission drive components, ideally suited for design applications where the non-contacting components result in ultra low dust generation. These applications include many cleanroom assembly operations in the semiconductor, circuit board, business appliance, military ordnance, aerospace and consumer electronics markets. Additional applications include those where the low noise and minimal vibration caused by these components are critical to the assembly or transfer mechanism performance.
These magnetic drive components from Misumi operate on the principle of attractive force and thus function without contact. Depending on the transmission direction desired, Type MDQ allows perpendicular alignment, while Type MDY allows parallel alignment. All components are housed in 5056 aluminum with a gas emission prevention treatment. Outside diameters from 16-35mm and inside diameters from 6-20mm are offered, with unit prices starting at $34.00. Standard delivery is eight days.
Once the alignment configuration is known, a designer can calculate the required quantity needed, based on the size and distance of the workload to be carried. Then, a calculation of the required torque can be made, based on the weight of the workload and specified quantity ordered.
Misumi magnetic transmission drive components are ordered in pairs and should not be used with other manufacturers' magnets or components.
All flux rate by temperature, torque rate by distance change and magnetic flux density by distance from the drive specifications are included in the new Misumi catalog, which can be ordered in print or accessed online.
For more information and full pricing on these unique products, please visit our website at www.misumiusa.com . Application assistance is always available from Misumi engineers.
About MISUMI USA, Inc.- Located in Schaumburg, Illinois, MISUMI USA, Inc. was established in 1988 as a Subsidiary of Misumi Corporation, a part of the Misumi Group (TYO: 9962). MISUMI USA, Inc. is a leading supplier of fixed and configurable components such as single-axis actuators, linear shafts, aluminum extrusions, linear guides, XY stages and other components for factory automation and various machine builds. For a complete list of available components, please visit www.misumiusa.com.
