Dissolved Ozone Analyzer targets USP and ultrapure water applications.
January 24, 2008 -
Able to read and measure low concentrations of dissolved ozone at ppb level, dFFOZ-TR Trace Dissolved Ozone Analyzer is suited for measuring residual ozone in predestruct and postdestruct water loops. Drift-free device utilizes UV light absorption technology and is immune to cross-interference from other gases. Protected in NEMA 4X enclosure, it features replaceable UV lamp that provides service life up to 18 months.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
IN USA, Inc.
87 Crescent Rd.
Needham, MA, 02494
USA
Dissolved Ozone Analyzer for USP and Ultrapure Water Applications Introduced by IN USA Corp.
Norwood, Massachusetts, USA - The new dFFOZ-TR Trace Dissolved Ozone Analyzer from IN USA Inc. is an ozone-specific measuring instrument that accurately reads and measure low concentrations of dissolved ozone at the ppb level for ultrapure water applications. This sensor is best suited for continuous measurement of traces of dissolved or residual ozone in USP and Ultrapure water in Bio-Pharmaceutical and Semiconductor applications. It is ideal for measuring residual ozone in pre-destruct and post destruct water loops where the concentrations are typically down in the single PPB levels.
The Model dFFOZ-TR uses patented ultraviolet (UV) light absorption technology to achieve accurate, stable readings down to the single digit ppb levels. Unlike conventional electrochemical-based ozone sensing devices, the dFFOZ-TR is extremely sensitive and drift-free. Due to its UV absorption technique, it is highly specific to dissolved or residual ozone and immune to cross interference from other gases. This ability eliminates the likelihood of false alarms, which can unnecessarily interrupt production cycles.
The dFFOZ-TR is rugged and reliable, with no moving parts to fail. It is environmentally protected in a compact NEMA-4X enclosure, and does not require periodic maintenance, thus delivering a lower cost of ownership. Unlike electrochemical sensors, the dFFOZ-TR requires no consumables such as electrolytes and membranes, which in electrochemical sensors need frequent replacement. Its easy-to-replace UV lamp provides a service life up to eighteen (18) months. With the dFFOZ-TR IN USA offers a dedicated MiniSCI-N controller. The MiniSCI-N is a microprocessor based system housed in a very compact wall mount Nema 4X enclosure. The MiniSCI-N is configured with a very clear alphanumeric display and includes analog and digital interface as well as three user-programmable alarm relays.
IN USA, Inc. is a leading developer and supplier of advanced ozone instrumentation and control systems. IN USA, Inc. offers a complete line of instruments for ozone measurement in air and liquid phases. For more information, visit www.inusacorp.com, or contact the company at 100 Morse Street, Norwood, MA 02062, USA, Toll free: 1-800-798-4029, Phone: (1) 781-444-2929, Fax: (1) 781-444-9229; E-mail: info@inusacorp.com.
|
|
|
|
|
|
|
|
