Display Driver is optimized for GIP-based LCD TVs.
March 4, 2009 -
Integrating high-speed operational amplifier to drive LCD backplane (VCOM), model MAX17108 enables implementation of gate-in-panel (GIP) technology in LCD panels. It includes 10-channel, level-shifting scan driver that can swing from -12 to +38 V and drive capacitive loads, and one linear regulator to provide internal bias for step-up controller. Amplifier features rail-to-rail outputs, ± 200 mA output short-circuit current, 100 V/µs slew rate, and 20 MHz bandwidth.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Maxim Integrated Products
120 San Gabriel Dr.
Sunnyvale, CA, 94086
USA
High-Performance Level-Shifter Solution for LCD TVs with Gate-in-Panel (GIP) Technology
o The MAX17108 is a 10-channel, level-shifting scan driver with an integrated operational amplifier for gate-in-panel (GIP) LCD TVs and monitors.
o Developed using Maxim's proprietary, high-voltage BiCMOS process, this device provides a high-performance level-shifter solution that enables the use of GIP technology in LCD panels.
o The MAX17108 is optimized for GIP-based LCD TVs and monitors.
SUNNYVALE, CA-January 29, 2009-Maxim Integrated Products (NASDAQ: MXIM) introduces the MAX17108, a high-performance level-shifter solution that enables the implementation of GIP technology in LCD panels. Developed using Maxim's proprietary, high-voltage BiCMOS process, this device integrates a 10-channel, level-shifting scan driver that can swing from -12V to +38V and swiftly drive capacitive loads; a high-speed operational amplifier to drive the LCD backplane (VCOM); and a linear regulator to provide the internal bias for the step-up controller. Optimized for GIP-based LCD TVs and monitors, the operational amplifier features rail-to-rail outputs, a ±200mA output short-circuit current, a 100V/µs slew rate, and a 20MHz bandwidth.
The MAX17108 is available in a 5mm x 5mm, 28-pin TQFN package and is fully specified over the -40°C to +85°C extended temperature range. Prices start at $2.00 (1000-up, FOB USA).
