Series 26DBM Digital Linear Actuator(DLA)
THOMSON AIRPAX MECHATRONICS INTRODUCES NEW DIGITAL LINEAR ACTUATOR THAT OFFERS HIGH PERFORMANCE IN A SMALL PACKAGE
Ronkonkoma, NY -- Thomson Airpax Mechatronics - a world leader in stepper motor technology - announces a bidirectional digital linear actuator (DLA) that provides high linear resolution as fine as .0005 in. per pulse.
The new actuator is ideal for precise, measured control of fluids and gases in such applications as HVAC refrigerant flow control, and measurement and dispensing of medical fluids.
Called "Series 26DBM," the DLA is a modified rotary stepper motor, with a rotor that includes an internally molded thread that mates to an externally threaded shaft (lead screw). Rotary motion is converted to linear movement, with the travel per step determined by the pitch of the lead screw and step angle of the motor.
Energizing the unit's coils (unipolar and bipolar) in proper sequence causes the threaded shaft to move out of, or back into the rotor in precise linear increments. When power is removed, the actuator shaft remains in position.
Weighing only 1.2 oz. (34 g.) with a maximum pull-in rate of 600 step/sec, the 24 models in the Series 26DBM feature two magnet types - Ferrite or Neodymium - and a linear force up to 8 lbs.
Series 26DBM is rated with a maximum travel rate of 0.52" (13.2mm) and a maximum linear force (2 phases energized) of 128 oz (35.6N).
Other key features include:
- radial ball bearing construction for high efficiency
- two voltage ratings - 5VDC and 12VDC
- linear travel per step -- .0005 in. (0.013 mm), .001 in. (0.025 mm), .002 in (0.050 mm)
- power consumption - 3.4 watts (1.7 input power per winding)
- operating temperature range -- -20°C - 70°C
- insulation resistance of 20 Ohm
Thomson Airpax Mechatronics can provide electrical and mechanical changes tailored to individual application requirements.
For technical assistance, call a Thomson Airpax Mechatronics engineer at 1-888-554-6684, or 631-467-8000, fax 631-981-0593, or E-mail: motorinfo@thomsonmail.com. Samples are available from stock. Unit pricing in 1-10 pieces is $53.00.
