Design Software models power supplies for FPGAs.
September 13, 2010 -
Incorporating detailed supply requirements of more than 130 FPGA devices from Altera Corp. and Xilinx, Inc., WEBENCH® FPGA Power Architect automatically populates unique power requirements, identifying core and I/O options for every potential load of that array. Once tuned by designer, WEBENCH collects all loads and creates multiple power supply architectures as options for driving FPGA and total system. User can share complete system with others or print project report including schematics and BOM.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
National Semiconductor Corp.
2900 Semiconductor Dr.
Santa Clara, CA, 95051-0695
USA
National Semiconductor Launches New WEBENCH FPGA Power Architect
New Tool Accelerates Design of Multiple Load Power Supplies for Altera, Xilinx FPGAs
SANTA CLARA, Calif. - National Semiconductor Corp. (NYSE:NSM) today introduced WEBENCH® FPGA Power Architect, the industry's first design tool to model and optimize power supplies for FPGAs in minutes.
WEBENCH FPGA Power Architect incorporates the detailed supply requirements of more than 130 of the newest FPGA devices from Altera Corp. and Xilinx, Inc. Modern power supply systems, including advanced FPGAs, are complex to design, often incorporating multiple unique loads to drive precisely specified voltages. In addition to the required voltages and currents, each load may have specific limitations for ripple, noise filtering, synchronization and separation of supplies, as well as start up definitions (soft start). The power supply designs delivered by WEBENCH incorporate comprehensive power requirements published by the FPGA manufacturers, giving the designer confidence that their power supplies will meet these constraints while saving critical time in the process. Watch a video demonstration at http://bit.ly/videoFPGA.
"Xilinx has made a considerable investment in simplifying the power supply requirements and the power distribution system requirements for our FPGAs," said Jameel Hussein, technical marketing manager for Power and Configuration Solutions at Xilinx. "With the help of National Semiconductor's WEBENCH FPGA Power Architect, design workload is further reduced to allow the customer to get to market faster and save cost on board-spins and debugging."
To begin a design, the designer selects an advanced FPGA from Altera or Xilinx and the tool automatically populates the unique power requirements, identifying core and I/O options for every potential load of that array. Once tuned by the designer, WEBENCH collects all the loads and creates multiple power supply architectures as options for driving the FPGA and the total system.
"A real system always includes much more than just the FPGA. We are making it easy for designers to quickly model their complete system power needs and include the unique requirements of their FPGA with confidence," said Phil Gibson, vice president of Technical Sales Tools at National Semiconductor. "We are helping them avoid mistakes and save countless hours of research and development time."
The power supply may involve one or more intermediate voltage rails between the input supply and the point-of-load regulators. The designer can tune the recommended power supply with the turn of a dial, reducing size, increasing efficiency or lowering complete system cost in seconds. The designer can also order components for prototyping, share the complete system with others, or easily print a complete project report including schematics, bill of materials (BOM) and performance characteristics.
To begin a design, visit http://national.com/FPGAarchitect.
About National's WEBENCH Designer Tools
National Semiconductor's award-winning online and offline WEBENCH power, lighting, and sensing application design tools are used by expert and novice electronic and mechanical engineers worldwide to create over 400,000 electronic designs each year. Available in English, Japanese and Simplified Chinese languages, the tools enable the design engineer to simultaneously compare the performance of different implementations across vendors and devices in multiple circuit requirements in one easy-to-use application. To begin a design, visit http://www.national.com/webench.
About National Semiconductor
Headquartered in Santa Clara, Calif., National Semiconductor is a leader in power management technology. Known for its easy-to-use analog integrated circuits and world-class supply chain, National's high-performance analog products enable its customers' systems to be more energy efficient. Additional information is available at www.national.com.
National Semiconductor and WEBENCH are registered trademarks of National Semiconductor Corporation. All other trademarks are the property of their respective owners.
