Connector Strips come in right angle and edge mount versions.
July 8, 2009 -
Designed for perpendicular and co-planar applications, .8 mm pitch Right Angle (EFM8-RA/ERF8-RA) and Edge Mount (ERM8-EM/ERF8-EM) terminals and sockets offer up to 150 IO in single-ended or differential pair configurations with choice of 10-75 positions per row based on orientation. They feature Edge Rate(TM) contacts, which minimize broadside coupling and decrease crosstalk between adjacent contacts. Suited for harsh environments, strips feature optional rugged metal latching system.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Samtec, Inc.
P.O. Box 1147
New Albany, IN, 47151 1147
USA
Samtec Expands Rugged Edge Rate(TM) Interface Family
Samtec has expanded its Edge Rate(TM) product line with the addition of .8mm (.0315") pitch Right Angle and Edge Mount connector strips for perpendicular and co-planar applications. These systems feature Samtec's rugged Edge Rate(TM) contacts which minimize broadside coupling, decrease crosstalk between adjacent contacts, and offer low insertion/withdrawal forces and high cycles.
Edge Rate(TM) Right Angle (EFM8-RA/ERF8-RA) and Edge Mount (ERM8-EM/ERF8-EM Series) terminals and sockets offer up to 150 I/Os in single-ended or differential pair configurations with a standard choice of 10 to 75 positions per row (dependant on orientation). Ideal for rugged and harsh environments, these strips are robust when zippered during unmating and feature an optional rugged metal latching system.
These new Right Angle and Edge Mount connectors may also mate with the Edge Rate(TM) board stacking system (ERM8/ERF8 Series). Cable mates for the strips include 34 AWG EyeSpeed(TM) Micro Coax High Speed (ERCD Series) and Signal Integrity-optimizing "Direct-to-Lead" (ERCDA Series) Cable Assemblies, 30 AWG EyeSpeed(TM) Twinax High Speed Cable Assemblies (ERDP Series), and High Speed Flex Data Links with Edge Rate(TM) contacts (ERDL2 Series).
Prices are approximately $ .11 per mated line depending on connector configuration and quantity.
For more information on Samtec's complete line of Edge Rate(TM) Interfaces, contact:
Samtec, Inc.
520 Park East Blvd.
P.O. Box 1147
New Albany, IN 47151-1147
Phone: 1-800-SAMTEC-9 or 812-944-6733
Fax: 812-948-5047
Internet: http://www.samtec.com
E-mail: info@samtec.com.
|
|
|
|
|
|
|
|
