Compression Molding Press is suited for cleanroom use.
November 7, 2003 - Bench-top Model PS3H-8-CLX features precision control of clamp force via proportional pneumatic pressure control system. Integral vacuum chamber has 8 x 8 in., electrically heated (up to 650F), and water-cooled platens. Closed loop pressure control provides 50–6,000 lb force and requires 100 psi compressed air source. Fully programmable, computer-based controls dictate all operating parameters and enable data storage.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Wabash MPI
1569 Morris St., P.O. Box 298
Wabash, IN, 46992 0298
USA
Wabash Pneumatic Vacuum Compression Molding Press
A new compression molding press featuring precision control of clamp force through a proportional pneumatic pressure control system has been introduced by WABASH MPI. Closed loop pressure control provides 50 lb. to 6,000 lb. force and requires only 100 psi compressed air source (typically available from in-plant system). The press is ideal for vacuum chamber compression molding of a variety of plastics and rubber requiring precise low pressure force control including testing, prototyping and production applications. It is very quiet operating and is ideal for clean room use (no hydraulics).
Fully programmable, computer-based controls dictate all operating parameters including temperature and pressure and provide for data storage. The press, Model PS3H-8-CLX, is equipped with integral vacuum chamber, 8” x 8” electrically heated (up to 650F) and water cooled platens. It can be engineered with and without vacuum chamber, integral vacuum pump and water cooling. It is fundamentally a bench top design (shown with optional floor stand). Standard electrically heated platens are available in sizes to 18” x 18”.
For more information contact WABASH MPI, PO Box 298, Wabash, IN 46992-0298. Phone 260-563-1184. Fax 260-563-1396. E-mail: wabashmip@corpemail.com. Internet www.wabashmpi.com.
|
|
|
|
|
|
|
|
