Bevel Gearboxes have compact, rigid design.
July 25, 2005 - Featuring 54 mm main body with 11 mm dia drive shafts, PowerGear size 54 gearbox is offered in 2 designs: standard P54 and reinforced shaft X54. Both provide up to 17 Nm output torque at up to 8,000 rpm, are lubricated for life, and offer fretting-free torque transfer. Type P54 is available in 4 gear ratios up to 3:1, and X54 suits applications requiring 1:1 ratio unit capable of handling increased torque while utilizing same gearbox case as P54 unit.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Power Jacks Limited
Maconochie Road
Fraserburgh, Aberdeenshire, , AB43 8TE
United Kingdom
Extended Neeter PowerGear Range
Neeter Drive has extended the PowerGear range of bevel gearboxes with the introduction of a new size in two designs. The new “size 54” gearbox is designed to offer the same high torque characteristics of the other PowerGear units but in a smaller size. The main body of the unit is only 54mm cubed with 11mm diameter drive shafts, but still capable of providing up to 17Nm of output torque at up to 8000 rpm. The two designs available are the standard P54 and the reinforced shaft X54. The X54 variant is designed for applications requiring a 1:1 ratio unit capable of handling greater torque than the standard P54 unit utilising the same gearbox case. The P54 in contrast is available in four gear ratios up to 3:1 as standard.
The units’ design gives the following advantages:
The compact and rigid design assures highest performance in a small footprint.
Lubricated for life, the gearboxes are, depending on their size, maintenance free, if operated under normal conditions.
Fretting-free torque transfer using a friction locked fit between shaft and bevel gear.
Typical applications for the PowerGear are angular torque transfer and torque distribution in single, or multiple shaft configurations. In non-stationary applications where weight is extremely important, the PowerGear design is the ideal solution.
For further information on the New PowerGear bevel gearboxes or any of our other products, please contact us on +44 (0) 1346 513131 or visit the website at www.powerjacks.com
|
|
|
|
|
|
|
|
|
|
|
