AC/DC Power Supplies target embedded systems.
February 23, 2012 -
Accepting 88-264 Vac input from 47~63 Hz, 25 W Model PS-RS25-5 delivers +5 Vdc at 5 A while 50 W Model PS-RS50-5 supplies +5 Vdc at up to 10 A. Convection-cooled units include short circuit and overvoltage protection, which will recover and return to normal automatically after fault is removed. Operating from -20 to +70°C without fan, Models PS-RS25-5 and PS-RS50-5 measure 79 x 51 x 28 mm and 99 x 97 x 36 mm, respectively, and are both UL60950-1 and TUV EN60950-1 approved.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
WinSystems, Inc.
715 Stadium Dr.
Arlington, TX, 76011
USA
Low-Cost 25W and 50W Embedded Power Supplies by WinSystems
Universal 88 to 264 VAC input; +5 Vdc out with either 5 or 10 Amps
Arlington, TX - WinSystems today introduced two small, convection cooled, AC/DC power supplies for embedded systems. The PS-RS25-5 is a 25W unit capable of supplying +5Vdc @ 5A while the 50W, PS-RS50-5, supplies +5Vdc @ up to 10A. The outputs have short circuit and overvoltage protection which will recover and return to normal automatically after the fault is removed. Both power supplies accept 88 to 264VAC input from 47~63 Hz so that they can work on AC mains throughout the world. The units operate from -20° to +70°C without the need for a fan.
Each unit meets various safety, EMI, and EMC standards. Both are UL60950-1 and TUV EN60950-1 approved. For EMI and conduction and radiation, each unit complies with EN55022 (CISPR22) Class B. Additionally both power supplies are compliant with EN61000-4-2, 3, 4, 5, 6, 8, 11: ENV50204, EN61000-6-2 (EN50082-2) heavy industry criteria A for EMS immunity.
The smaller PS-RS25-5 measures only 79 x 51 x 28mm. The slightly larger PS-RS50-5 measures 99 x 97 x 36mm.
There are four different ordering options for each power supply. These options come with a USA standard AC plug. The variations are defined by the DC harness for WinSystems' embedded SBCs that conform to the PC/104, EPIC, EBX standards or with no DC harness at all.
PRICING AND AVAILABILITY
The PS-RS25-5-0 is priced at $33 (qty. = 1). The PS-RS50-5-0 is priced at $39 (qty. = 1). Delivery is from stock. For sales information, please list; WinSystems' Application Engineering Group at 715 Stadium Drive, Arlington, Texas 76011, Ph: (817) 274-7553, fax: (817) 548-1358, Website http://www.winsystems.com and the e-mail: info@winsystems.com.
The PS-RS25-5's data sheet is located at http://www.winsystems.com/products/misc/PS-RS25-5.cfm. The PS-RS50-5's data sheet is located at http://www.winsystems.com/products/misc/PS-RS50-5.cfm.
ABOUT WINSYSTEMS
WinSystems designs and manufactures industry-standard PC/104, EPIC, EBX, Pico-I/O, SUMIT-ISM, and STD Bus single board computers (SBCs), I/O modules, and enclosures for use by OEMs and system integrators worldwide. We have served the industrial market for 30 years. We are an employee-owned company.
|
|
|
|
|
|
|
|
