AC/DC Modules combine safety approvals, 78% efficiency.
November 11, 2009 -
Operating from 85-260 Vac or 110-370 Vdc input, UL60950-1 approved LD03 Series comes in PCB-mount, encapsulated package for test and measurement, industrial control, communications, and consumer electronic products. Input to output isolation of 4,000 Vdc and EN60601-1 safety approvals on LD05 Series suit patient vicinity medical device designs. Both RoHS-compliant switching power supplies offer single output voltages, which range from 3.3-24 Vdc and are tightly regulated to ±1%.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Original Press release
Mornsun America
43 Broad Street
Hudson, MA, 01749
USA
New AC/DC Modules Feature EN60950-1 and EN60601-1 Safety Approvals
Mornsun augments their low cost, encapsulated AC/DC module family with the LD03 and LD05 Series' of switching power supplies.
With universal inputs of 85~260VAC or 110~370VDC and a low profile PCB mountable encapsulated package, the UL60950-1 approved LD03 Series is ideally suited for a wide variety of applications including test and measurement equipment, industrial control devices, communications applications and consumer electronic products. Input to output isolation of 4000VDC and EN60601-1 safety approvals on the LD05 Series, make it an excellent choice for patient vicinity medical device designs.
Single output voltages range from 3.3VDC to 24VDC and are tightly regulated to ±1%. Units boast low ripple and noise of 30mV p-p and efficiency is specified as high as 78%. Comprehensive protection circuitry includes short circuit, over temperature, and output over voltage protection.
The LD Series power converters use high quality, 100% RoHS compliant materials and are manufactured to Mornsun's rigorous, ISO-9001 quality control program to ensure high product reliability.
Competitively priced, with LD05 units starting at $7.60 in OEM quantities, availability is from stock to 8 weeks ARO. Full specifications are available at www.mornsunamerica.com or by contacting our Tech Group at tech@mornsunamerica.com. For price and delivery questions, please contact us at sales@mornsunamerica.com
|
|
|
|
|
|
|
|
|
|
|
