May 1, 2009 -
Model H4PD sensor provides ±22° dual axis inclination sensing in rugged IP66 environmentally protected die-cast zinc housing. Unit incorporates MEMS sensing element referenced to gravity with integrated temperature compensation over industrial operating range of -40º to +85ºC. PWM output is linear with respect to input angle directly. OEM-ready device is EMC protected, vibration and shock resistant, and offers mechanical zero adjustment.
Rieker Incorporated Introduces the New Dual Axis MEMs based inclinometer to the H4 Series
The H4PD sensor provides dual axis inclination sensing in a rugged environmentally protected housing. This unit incorporates a MEMS (Micro-Electro-Mechanical Systems) sensing element referenced to gravity with integrated temperature compensation over the industrial operating range of -40º to +85ºC. The PWM (Pulse Width Modulated) output is linear with respect to the input angle directly.
Small dimensions and common footprint make it easy for field replacement.
The housing footprint is designed for retrofitting in the field without re-drilling mounting holes (common placement of center and slider flanges).
Features:
o Dual Axis Angle Measurement
o Digital Pulse Width Modulated Output
o Range: ±22°
o Temperature Compensated Output
o Operating Temperature -40/+85°C (-40/+185°F)
o Vibration and shock resistant
o Environmentally sealed to IP66
o Rugged die-cast zinc housing
o EMC protected
o Mechanical Zero adjustment
Applications:
o Leveling and Tilt/Slope Monitoring
o Platform Leveling
Equipment:
o Material Handling/Process Control Equipment
o Aerial Lifts
o Scissor Lifts
o Boom Lifts
o Cranes and Derricks
o Lift Equipment/Vehicles
OEM Ready
Contacts:
Marketing:
Skip Gosnell Marketing Director
USA E-mail this person Company Information: Name: Rieker Instrument Co., Inc. Address: P.O. Box 128 777 Henderson Blvd, Park Sq N Bldg, Bay #6 City: Folcroft State: PA ZIP: 19032 Country: USA Phone: 610-534-9000 FAX: 610-534-4670 http://www.riekerinc.com
