Programmable Dispensing System uses precision stepper motors.
October 16, 2008 -
PDS-100 Programmable Dispensing System uses precision stepper motors to control valveless piston pumps and offers range of 500 nl per dispense to 2 lpm continuous flow. It accommodates all FMI pump sizes in both fixed and adjustable displacement configurations. Pump heads are mounted to control unit, which is housed in rugged anodized aluminum enclosure that has LED readout to display menu driven programming, as well as membrane switches for navigating through programming steps.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
New The Ultimate in Programmable Dispensing Systems
The NEW PDS-100 from Fluid Metering Inc. is a Programmable Dispensing System which uses precision stepper motors to control a variety FMI's patented valveless piston pumps.
The PDS-100 has a range from 500 nanoliters per dispense to 2 liters per minute continuous flow. It will accommodate all FMI pump sizes in both fixed and adjustable displacement configurations.
The pump heads are integrally mounted to the control unit which is housed in rugged anodized aluminum enclosure. The control unit includes the stepper motor drives as well as programmable driver electronics.
The front face of the enclosure has an LED readout used to display menu driven programming, as well as membrane switches for navigating through the programming steps.
The PDS-100 can be configured to control either one or two pump heads. In configurations with 2 pump heads, each pump can be controlled independently for dual proportional dispensing & metering or synchronized to produce a smooth, pulseless flow.
Fluid Metering, Inc. has nearly 50 years experience providing dispensers and pumps for the most critical low flow, high precision applications.
For additional information, Call toll free 1-800-223-3388 or 1-516-922-6050, FAX 1-516-624-8261, email: pumps@fmipump.com or visit our website at www.fmipump.com, which now features "Live Help", an online direct connection to FMI's application experts.
Fluid Metering, Inc.
5 Aerial Way - Suite 500
Syosset, NY 11791 USA
Contacts:
Public Relations:
Beehive Marketing Group, Inc.
George Bienenstock
PO Box 7099
Bedminster NJ 07921
USA
Phone: 908-470-0369 E-mail this person Company Information: Name: Fluid Metering, Inc. (FMI) Address: 5 Aerial Way, Suite 500-T City: Syosset State: NY ZIP: 11791 Country: USA Phone: 800-747-5858 FAX: 516-624-8261 http://www.fmipump.com/TR
