Power Connector comes with TPE molded insulating sleeves.
October 8, 2008 -
With rubber molded TPE Santoprene 135°C rated insulating sleeves, Watertight Single Pole Cam-Lok Connectors feature hex contact design that eliminates possibility of contact rotation within sleeve with minimum of 700 lb shear force. They meet OPNAVINST 11310.3B specifications, and are rated 600 V, 690 A, 60 Hz continuous duty operation. Termination types include single crimp style, solder, single set screw, and double set screw.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Duraline Introduces Its Single Pole Power Connectors with TPE Molded Insulating Sleeves Indoor/Outdoor Use
DuralineŽ, a leading manufacture of lighting streamers and other electrical power distribution systems for over 50 years, announces its' Watertight Single Pole Cam-Lok Connectors with Rubber Molded TPE Santoprene 135°C rated Insulating Sleeves. Features new Hex Contact design that eliminates the possibility of contact rotation within the TPE Santoprene molded insulating sleeve with a minimum of 700 lbs shear force. Built to meet and exceed the Department of the Navy OPNAVINST 11310.3B Specifications
Connectors are rated 600 volts 690 Ampere 60 Hertz Continuous Duty Operation. Termination Types Include Single Crimp Style, Solder, Single Set Screw and Double Set Screw. TPE Sleeve Service Temperature Range -60°C to +135°C, UL94 HB Rated, RTI 100°C, Durometer ASTM D 2240, 55-65A. Available in Ball Nose and Tapered Nose Cam Lok Styles
Duraline, a division of J.B. Nottingham & Co.,Inc., is a leading manufacturer of safety engineered electrical power distribution systems designed to withstand rough handling and severe weather conditions. Established in 1946 as a supplier of heat-treating distribution systems to the US Navy, Duraline's principle offices and manufacturing facilities are located in Long Island, New York. Duraline sells and services it's specially engineered systems throughout the United States and Canada.
For more information on the New Single Pole Power Connectors go to http://store.jbn-duraline.com/category/244/ or contact Duraline, 75 Hoffman Lane, Islandia, NY 11749. Call: 631-234-2002, or Fax: 631-234-2360.
Visit Duraline's Store on the World Wide Web at http://store.jbn-duraline.com. Company Information: Name: Duraline Div., J.B. Nottingham & Co., Inc. Address: 75 Hoffman Lane City: Islandia State: NY ZIP: 11749 Country: USA Phone: 631-234-2002 FAX: 631-234-2360 http://www.jbn-duraline.com
