Battery Straps connect 9 V batteries in series or parallel.
July 16, 2008 -
Available in T or I configurations, Insulated Battery Straps are made of molded Polyethylene or rigid fiber which incorporates insulators and sturdy Phosphor Bronze or Spring Steel, Nickel-plated, snap-on connectors. They feature soldered-in #26 AWG red and black wire leads in lengths of 4.00, 6.00, and 8.00 in. each vinyl covered, and 4.00, 6.50, and 8.00 in. each fiber covered. Shielded types, which reduce short circuit and contact tampering potential, are also offered.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Astoria NY - High performance, pre-wired, and competitively-priced 9V Insulated Battery Straps, designed to connect most 9V batteries in series or in parallel, are now available from Keystone Electronics Corp.
Keystone's high performance "Premium" design is made of molded Polyethylene or rigid fiber which incorporate high quality insulators and sturdy proven Phosphor Bronze or Spring Steel, Nickel-plated, snap-on connectors. Available in "T" or "I" configurations, these straps provide greater dependability while featuring soldered-in #26AWG red and black wire leads; three (3) lengths - 4.00"(101.6mm), 6.00"(152.4mm), and 8.00"(203.2mm) each vinyl covered; and 4.00"(101.6mm), 6.50"(165mm) and 8.00"(203.2mm) each fiber covered. Shielded types which reduce short circuit and contact tampering potential, are also offered.
A cost-saving alternative, the company's "Economy" group features a similar design and is available in "T" o "I" configurations. Fully insulated, these have Brass, Nickel-plated contacts with a molded ABS or vinyl covered bases. Wire lengths are 4.00" (101.6mm), 6.00" (152.4mm) or 8.00" (203.2mm). Lead lengths are in red and black.
The third style (PN 227) is a pre-wired "Dual" battery strap which connects 9V batteries in parallel. These are manufactured with fiber bases and have Steel, Nickel-plated contacts. Featured are pre-tinned #22AWG red and black leads; and wire lengths of 7.00" (178mm) length, soldered-in for exceptional reliability.
The company's full line of battery hardware engages SMT and thru-hole applications and includes clips, contacts, holders, retainers, plus straps in various materials for an assortment of battery styles.
Keystone Electronics Corporation offers a comprehensive assortment of interconnect hardware and components, as well as stamping, machining, and assembly services. For modifications and special designs, Keystone also offers applications-engineering services. Keystone is ISO 9001 certified, RoHS compliant with headquarters in the US and offices in Canada, Europe, Australia and Asia.
For more information, contact
Keystone Electronics Corp.,
31-07 20th Road,
Astoria NY 11105-2017,
(800) 221-5510;
fax (718) 956-9040;
e-mail: kec@keyelco.com;
