Transducers suit industrial and hazardous applications.

May 28, 2008 - PT-400 Amplified Output Pressure Transducers provide minimum of 10 million operating cycles with accuracy of ±0.25% F.S. (B.F.S.L.), in operating temperatures from -40 to 180°F. They are cCSAus certified for use in hazardous locations, weigh 10 oz, and offer standard 4-20 mA, 0-5 Vdc, and 0-10 Vdc outputs. Units feature pressures ranging from 0-20,000 psi, along with high burst pressure to 3x full scale and overpressure to 2x full scale for in-process reliability.

Related categories: Sensors, Monitors and Transducers | Test and Measuring Instruments

Press Release
Release date: May 20, 2008

Automation Products Group Introduces PT-400 Pressure Transducers for Industrial and Hazardous Applications

Cost effective and durable solution in applications requiring high accuracy and reliability over wide range of pressures

LOGAN, UT - Automation Products Group, Inc. (APG) introduces PT-400 Amplified Output Pressure Transducers. PT-400 pressure transmitters provide a minimum of 10 million operating cycles with high accuracy of ±0.25% F.S. (B.F.S.L.), in operating temperatures from -40 to 180°F. Additionally, these sensors cover pressures ranging from 0 up to 20,000 psi, along with high burst pressure to 3x full scale (limited by the process connection) and overpressure to 2x full scale for in-process reliability. The PT-400 is designed for demanding applications in oil drilling, water and wastewater industries as well as for general use in other industries.

PT-400 pressure transducers weigh just 10 oz. (283 g) and offer standard 4-20mA, 0-5 VDC and 0-10 VDC outputs. Their integrated electronics are fully enclosed inside an all-welded stainless steel housing with a ¼-18 NPTM fitting is standard. Even with the rugged stainless steel housing, users still have access to zero and span adjustments for calibration to specific application requirements. Their rugged construction and performance attributes make them well suited for static and dynamic pressure measurement where an amplified output signal is desired. A number of options, including extended temperature compensation, higher accuracy ratings and alternate process fittings, among others, are available.

The transmitters are cCSAus certified for use in Hazardous locations. Units with 0-5 VDC, 0-10 VDC and 4-20 mA outputs are rated for Class I, Div. 2, Groups C and D, and Class I, Zone 2, Group IIB hazardous locations. In addition, units with 4-20 mA output are rated for cCSAus certified for use in Class I, Div. 1, Groups C and D, and Class I, Zone 0, Group IIB hazardous locations.

About Automation Products Group
Automation Products Group, Inc. (APG) supplies tailored sensing solutions for measurement applications to process control industries. They serve the water and wastewater, oil and gas, telemetry integration, car wash OEM, as well as cooking and lubricant oil recycling markets with a complete family of presence, level, flow and pressure sensing technologies. APG has roots in the sensor business spanning more than 35 years.

Automation Products Group, Inc., 1025 W. 1700 N., Logan UT 84321; toll-free: 1-888-525-7300; (435) 753-7300; fax: (435) 753-7490; E-mail: sales@apgsensors.com, Web site: www.apgsensors.com.

Customer Contact:
Charlie Strack
888/525-7300
charlies@apgsensors.com

Contacts:

Public Relations:
Chris Nelson
USA
Phone: 612-237-4443

E-mail this person

General Information:
Charlie Strack
USA
Phone: 888-525-7300

E-mail this person

Company Information:
Name: Automation Products Group, Inc.
Address: 1025 W. 1700 N.
City: Logan
State: UT
ZIP: 84321
Country: USA
Phone: 888-525-7300
FAX: 435-753-7490
http://www.apgsensors.com/
