Hydraulic Excavator comes with 7 in. multi-color monitor.
March 21, 2008 -
With net horsepower of 187 hp and operating weight of 65,336-67,393 lb, Model PC270LC-8 is equipped with low emission SAA6D107E-1 engine that reduces NOx emissions with multi-staged fuel injection system. Unit features EMMS (Equipment Management Monitoring System), which includes maintenance function and trouble data memory function. Standard overall width of 11 ft 2 in. provides lateral stability, while 56,000 lb of drawbar pull helps overcome poor underfoot conditions.
Komatsu America Corp. Announces New Hydraulic Excavator
PC270LC-8 Driven By Improvements In Efficiency, Operator Comfort And Fuel Economy
Rolling Meadows, IL, For CONEXPO - CON/AGG 2008- Komatsu America Corp. introduces its new PC270LC-8 hydraulic excavator. Distinguished by enhancements in efficiency and information technology upgrades, the hydraulic excavator offers improved operator comfort and a new low emission engine that improves fuel consumption. Primarily used for general contracting and underground utilities installation, this powerful excavator has a net horsepower of 187 HP and an operating weight of 65,336 to 67,393 pounds. The PC270LC-8 exemplifies the Komatsu design concept of matching highly efficient engines and advanced hydraulic systems to provide leading edge productivity and low-cost operation.
The new PC270LC-8 is standard-equipped with the latest Komtrax(TM) technology, which sends machine operating information to a secure website utilizing wireless technology. Data such as operating hours, location, cautions, and maintenance alerts are relayed to the web application for analysis. The Komtrax wireless equipment monitoring system increases machine availability, reduces the risk of machine theft, allows for remote diagnosis by the distributor, and provides a wealth of other information to drive business efficiency and productivity.
Special features of the new PC270LC-8 include:
o Low Emissions And Reduced Fuel Consumption,
The excavator is equipped with the newly-developed, powerful, low emission Komatsu SAA6D107E-1 engine that significantly reduces NOx emissions with an accurate multi-staged fuel injection system. The engine is EPA Tier 3 emissions certified without sacrificing power or machine productivity. The economy mode further improves fuel consumption with an eco-gauge for energy-saving operations and an operator caution for extended idling.
o Hydraulic System Complements Efficiency
Significant improvements to the hydraulic system greatly enhance the productivity and efficiency of the PC270LC-8 excavator. These include an improved pump flow merge divide valve, and high-efficiency hydraulic components which reduce pressure loss. In addition, the new arm quick return circuit reduces overall cycle times, thereby improving productivity even more.
o Operator Comfort A Top Priority
Komatsu's dedication to continually improve operator comfort ensures the highest levels of operator productivity and efficiency. The new innovative hydraulic excavator cab design continues to offer high visibility and is reinforced with a seamless tube structured cab framework to protect the operator in the event of a tip or rollover. Noise is significantly reduced to that of a premium automobile and the cab damper mounting system combines with a high rigidity deck for decreased cab vibration. The highly pressurized cab also has an automatic air conditioner with a bi-level control function for ultimate operator comfort. In addition, the seat and console are designed with console mounted armrests that enable the operator to adjust for maximum comfort.
o Large Multi-Color Monitor For The Best View
The easy-to-view 7-inch color monitor supports accurate and smooth work and displays data in 10 languages. For increased operator awareness, views from the standard equipped counter-weight mounted camera also display in color on the monitor. The multi-function monitor has a Power mode, Economy mode, Lifting mode, Breaker operation and Attachment mode
o Simple And Precise Breaker And Attachment Control
The PC270LC-8 offers fingertip command of two different breaker and attachment flow selections, providing a total of four flow settings. Each flow setting can be easily adjusted to match the demand of the attachment on hand, and the password protection system can be enabled to prevent unauthorized adjustment.
o Easy Maintenance And Lower Operating Costs
The PC270LC-8 is equipped with the EMMS (Equipment Management Monitoring System), which includes a maintenance function and trouble data memory function. The machine controllers continually monitor machine condition before start-up and during operation. Any abnormalities are immediately displayed. This smart monitor also notifies replacement time of oil and filters, and stores abnormalities for effective troubleshooting. All of Komatsu's conventional excavators come standard with the company's unique high-pressure in-line filters installed at each pump discharge port to provide additional hydraulic system protection with the already installed high efficiency return filters.
o Aggressive Productivity Features
The PC270LC-8 utilizes the next size class up (PC300) track frames and drive components such as the final drives and travel motors. The standard overall width of 11'2" provides exceptional lateral stability while the high 56,000 pounds of drawbar pull allows the machine to easily overcome poor underfoot conditions.
Komatsu America Corp. is a U.S. subsidiary of Komatsu Ltd. which is the world's second largest manufacturer and supplier of construction, mining and compact construction equipment. Through its distributor network, Komatsu offers a state-of-the-art parts and service program to support the equipment. Komatsu has proudly been providing high-quality reliable products for nearly a century. Visit the website at www.komatsuamerica.com for more information.
Peter Drummond
Komatsu America Corp.
847.437.4559
Contacts:
Public Relations:
Shawn-Laree de St. Aubin Dobbins Communications
USA
Phone: 847-332-2626
General Information:
Peter Drummond
USA
Phone: 847-437-4559 Company Information: Name: Komatsu America Corp. Address: One Continental Towers , 1701 W. Golf Road City: Rolling Meadows State: IL ZIP: 60008 Country: USA Phone: 866-513-5778 http://www.komatsuamerica.com
