Motor Drive runs brushless dc motors at constant velocity.
Motor Drive runs brushless dc motors at constant velocity.

Click Here to Enlarge Picture

Motor Drive runs brushless dc motors at constant velocity.


March 24, 2008 - Utilizing motor's Hall sensors for velocity feedback, ac-powered TA2230 measures 9.3 x 3.5 x 5.7 in. Output from 100-220 Vac @ 50/60 Hz, 25 A peak current supply is equivalent of 15,000 W PWM drive. DC voltage is 0-330 Vdc at 45 A peak, 20 A RMS continuous. Speed setting options offered are: external speed command via off-board 10K potentiometer, on-board potentiometer for fixed speed adjustment, and fixed speed set via software. Various other parameters are software configurable.

(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)

 See related product stories
Diesel Hybrid Electric Powertrain provides all-wheel drive.
Brushless DC Drives are suited for BDLC motors.
DC Brush Motor Driver is rated at operating level of 4 A.
Brushed Servo Drives accept bus voltage from 24-180 Vdc.
Intelligent Servo Drive reaches up to 600 W peak power.
 See more product news in:
Controls and Controllers
 Tools for you
del.icio.us DIGG
Facebook Reddit
StumbleUpon Twitter
Print This Page E-Mail Story
Watch_Company  Save Story
Contact company View Company Profile
Company web site
More news from this company

Advertisement
More Tools and information
Search for suppliers of
DC Drives
Electric Motor Drives
Join the forum discussion at:
 Tools of the Trade
 Newsletters
Your Gateway to a Fast Changing World
Product News Alerts
Receive similar stories and other customized news to keep you in the know on the products shaping industry.
Subscribe Free Today
Subscribe   View Sample

Industry Market Trends
Has Got It
  • Latest developments
  • Trends
  • Best practices
  • Opinions & Commentary
Get Ahead. Get IMT.
Subscribe Free Today
Subscribe   View Sample
 See more related product stories:
OEM Motor Drive provides positioning control.
Digital DC Drives are available in 2 and 4 quadrant options.
High Current DC Drives offer 50-200 A continuous current.
DC Drives feature 32-bit control architecture.
Single-/Dual-Axis Drives boost CNC platform flexibility.
Trapezoidal Drive is suited for DC brushless motors.
Intelligent Servo Drive controls motors up to 3 kW.
Digital DC Drives are available up to 1,050 A.
Positioning Stages offer ball screw drive decoupling system.
Roller Drive provides energy efficient conveying.
Minidrive features CANopen technology.
DC Drives feature rugged, compact design.
DC Motor Drive suits constant velocity applications.
DC Drives feature 20-20,000 Adc range.
Digital Brushless DC Drive displays speed and load factors.
Drive provides distributed motion control.
DC Drives suit OEM market.
Brushless DC Drive provides single-axis motion control.
DC Drives suit 4-quadrant regenerative applications.
Miniature DC Drive suits battery-powered applications.


New, High Efficiency, AC Powered Brushless DC Motor Drive for Constant Velocity Applications


March 13, 2008

San Luis Obispo, CA - Trust Automation has introduced the compact, low cost, programmable TA2230 constant velocity drive. The TA2230 drive is designed to run a brushless motor at a constant velocity using the motor's Hall sensors for the velocity feedback. Using an RS232 interface the drive can be programmed at start-up to ramp up at a preset rate and maintain a constant velocity regardless of changes in load. This low cost, highly efficient drive is ideal for new and existing industrial applications such as factory automation, machine tools, conveyors, injection molding machines, air compressors, pumps, and in existing applications where improved performance and lower operating costs are desired.

This compact brushless motor drive with the optional cooling fans measures just 9.3 in. X 3.5 in. X 5.7 in. Motor output from the drive with an AC supply of 100-220 VAC @ 50/60 Hz , 25 Amp peak current is the equivalent of a 15,000 Watt (45 Amp peak) PWM drive. The DC voltage is 0-330 VDC at 45 Amp peak, 20 Amp RMS continuous. Features of the TA2230 drive include three speed setting options: 1 - (Ext) external speed command via off-board 10K potentiometer, 2 - (Int) on-board potentiometer for convenient fixed speed adjustment, and 3 - (Soft) fixed speed set via software; as well as soft start control, integral AC line filtering, and self-contained, enclosed, and optically isolated user interface for safety. Some of the software configurable parameters include: Enable input level, Fault output level, Coast input level, Target velocity, Hall active level, and Current limit.

Trust Automation's motion control products include: Stand-alone motion and machine controllers, Linear servo amplifiers, SynqNet I/O, Brushed and Brushless Rotary Motors, Interconnect Products and Automation Engineering consulting covering Mechanical, Electrical, Software and System aspects of machine design. Since 1990 Trust Automation has provided Smart Solutions in Motion Control and Affordable Customization of motion related products.

For additional information contact
Dave Rennie at Trust Automation,
143 Suburban Road,
San Luis Obispo, CA 93401;
Tel: 805-544-0761,
Fax: 805-544-4621,
E-Mail: info@trustautomation.com
or visit the Web site at http://www.trustautomation.com.


Contacts:

General Information:
Dave Rennie
USA
Phone: 805-544-0761
FAX: 805-544-4621
Send email  E-mail this person

Company Information:
Name: Trust Automation, Inc.
Address: 205 Suburban Road
City: San Luis Obispo
State: CA
ZIP: 93401
Country: USA
Phone: 805-544-0761
FAX: 805-544-4621
http://www.trustautomation.com
