The long awaited answer to the problem of carbide insert changes. Now an inexperienced operator can change an insert in seconds! And without using any tools. It's a snap! The Click Change tool holder will pay for itself in just days of operation, not months or years.
The Click Change Tool Holder is a revolutionary development that allows a machine operator to change carbide inserts in seconds. Without tools, and without the high level of skill needed with old fashioned tool holders. It is built to last, and will take the toughest jobs in stride. The insert pocket won't distort over time as in other tool holders, and the repeatability is excellent.
The Click Change is a piece of production tooling that allows operators to be far more productive, which helps shops lower their overall labor costs and become more competitive. Comparing the Click Change to an old fashioned toolholder is like comparing a hand wrench to an air impact wrench. And, just like you won't find a
single tire shop that still uses old fashioned hand wrenches, it won't be long from now, when the old style tool holders will be a thing of the past. Equip your operation with Click Change Tools now, and get a jump on your competition.
AVAILABLE IN CNMG, WNMG, VNMG, AND MORE
AVAILABLE TOOLS:
Part Number Shank Insert
DCLNR/L 75", 1.00", 1.25" 4xx-CNMG
DCLNR/L 20, 25, 32mm 4xx-CNMG
DDJNR/L 75",1.00",1.25" 4xx-DNMG
DDJNR/L 20, 25, 32mm 4xx-DNMG
DWLNR/L 75",1.00",1.25" 4xx-WNMG
DWLNR/L 20, 25, 32mm 4xx-WNMG
GWLNR/L 75",1.00",1.25" 4xx-WNMG
GWLNR/L 20, 25, 32mm 4xx-WNMG
DVJNR/L 75",1.00",1.25" 3xx-VNMG
DVJNR/L 20, 25, 32mm 3xx-VNMG
FCLNR/L 500", .625",.75" 3xx-CNMG
FCLNR/L 12, 16, 20mm 3xx-CNMG
Coolant heads are available for all sizes.
(The GWLNR/L is a patent pending fork mechanism that insures zero insert movement.)
SPECIFICATIONS:
Specifications apply to all styles
Insert Clamping..... Positive Mechanical Lock
Insert replacement repeatability..... .0002"
Manual force to release lock.....8-10 lbs.
Manual force to engage lock..... 3-5 lbs.
Body & mechanism materials..... S7 Tool Steel
Theoretical drive spring life..... 100,000 cycles
Recommended lubrication interval......2 years
All components hardened to..... HRC 56-58
Internal adjustments or settings...... None
Wear components....... None
Insert geometry...... ISO/ANSI
Insert thickness range..... ±.005"
(Most designs will accept ±.010")
ONE YEAR WARRANTY ON MATERIALS AND WORKMANSHIP. 30 DAY CUSTOMER SATISFACTION GUARANTEE. 30 DAY NO OBLIGATION RETURN POLICY.
TOP NOTCH, BORING BARS, AND OTHER STYLES AND SIZES ARE COMING SOON.
See us Live & In person at:
WESTEC 2008 - Mar 31-Apr 3
EASTEC - May 20-22
iMTS 2008 - Sept 8-13
U.S. Patent No. 7,153,069, others Pending.
Foreign patents pending.
Company Information:
Name: Click Change Tooling Systems
Address: 21622 N. 14th Ave.
City: Phoenix
State: AZ
ZIP: 85027
Country: USA
Phone: 800-466-3131
FAX: 623-580-8008
http://www.clickchange.com
