Precision Diaphragm Chucks suit clamping applications.
Precision Diaphragm Chucks suit clamping applications.

Click Here to Enlarge Picture

Precision Diaphragm Chucks suit clamping applications.


March 11, 2008 - With TIR of 50 millionths, 5 in. DPS-5s Air Open Diaphragm Chuck features 8 sets of alloy steel jaws, hardened to 58/63 Rockwell C, that repeat to 1/10,000 when removed and replaced. Six different stops mount to center of chuck for positive axial location. For C.V. clamping, Special 7 in. counterbalanced diaphragm chuck has 3 pull down fingers. Jaws grip OD of C.V. joint while fingers pull it into fixed axial stop for zero axial location.

(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)

 See related product stories
Precision Air Chuck delivers precision at any speed.
Custom Diaphragm Chuck meets pneumatic pump industry needs.
Custom Diaphragm Chuck suits pneumatic pump applications.
Sliding Air Jaw Chuck is offered in various configurations.
Chucking Systems are available in 2 versions.
 See more product news in:
Machinery and Machining Tools
 Tools for you
del.icio.us DIGG
Facebook Reddit
StumbleUpon Twitter
Print This Page E-Mail Story
Watch_Company  Save Story
View Company Profile
Company web site
More news from this company

Advertisement
More Tools and information
Search for suppliers of
Precision Chucks
Diaphragm Chucks
Join the forum discussion at:
 Tools of the Trade
 Newsletters
Your Gateway to a Fast Changing World
Product News Alerts
Receive similar stories and other customized news to keep you in the know on the products shaping industry.
Subscribe Free Today
Subscribe   View Sample

Industry Market Trends
Has Got It
  • Latest developments
  • Trends
  • Best practices
  • Opinions & Commentary
Get Ahead. Get IMT.
Subscribe Free Today
Subscribe   View Sample
 See more related product stories:
Workholding Air Chuck offers 6 jaw force settings.
Diaphragm Chuck is developed for indicator manufacturers.
Milling Chucks come in 3 and 2 jaw configurations.
Workholding Chuck has drawbar activated design.
Diaphragm Chuck has no metal-to-metal moving parts.
Air Chuck suits driveshaft clamping applications.
Pneumatic Chuck suits boring, milling, lathe applications.
Precision Chuck facilitates circuit board drilling.
Mini Diaphragm Chuck suits micro machining applications.
Precision Power Chucks have dual actuator design.
Precision Diaphragm Chuck has built-in air cylinder.
Diaphragm Chuck has internal rotary union.
Collet Chucks have central through-coolant feature.
Face Clamping Chuck features center mounted diaphragm.
Diaphragm Chuck grips circulator pump bearing housings.
Diaphragm Chuck grips compressor scrolls.


Precision Diaphragm Chucks for Clamping


Northfield Precision Instrument Corporation is a leader in the design and manufacture of precision workholding air and diaphragm chucks. Northfield manufactures precision air chucks with a guarantee of accuracy within millionths. Northfield is pleased to announce it's new Special 5" Diaphragm Chuck for clamping applications.

Model DPS-5s is a special 5 inch diameter chuck, air open diaphragm clamp. Chuck has 8 sets of jaws that repeat to 1/10,000 when removed and replaced. Six different stops mount to center of chuck for positive axial location. Jaws are alloy steel hardened to 58/63 Rockwell "C". Chuck is mounted to a special balance machine that finds the center of gravity of the cast turbine blades and drills a centering hole in that position. The part is now rotated about this center instead of machining weight off different areas for balance. T.I.R. = 50 millionths, Axial = 0, cycle time 30 seconds.

In addition to Diaphragm Chuck Model DPS-5s we are pleased to introduce our Special 7" chuck for C.V. clamping. This counterbalanced diaphragm chuck has 3 pull down fingers. Jaws grip O.D. of C.V. joint while fingers pull it into the fixed axial stop for zero axial location. Chuck rotates 5 - 6,000rpm to balance C.V. joint driveshafts, T.I.R. = 50 millionths, Axial = 0, Cycle time 60 sec.

Northfield Precision designs and manufactures the world's most accurate workholding precision pneumatic Air and Diaphragm Chucks for any lathe, boring machine or grinder or VMC. Available in SAE or metric, in chuck sizes from 3" (76mm) to 18" (457mm). Accuracies of 0.001" to 0.00001" (0.254m) guaranteed.

We have come to be the Precision Workholding Source for air & diaphragm chucks with workholding leadership in accuracy, reliability, repeatability, concentricity, productivity and customer service. Quick change, thru-hole and coolant-thru chucks are available with engineered workholding consultation services for all your OEM applications. One competitive price for complete workholding system including chuck, top jaws, custom made air tube assembly, rotary joint, hoses, operating valve and accessory kit. No hidden extras.

Custom workholding chucks and jaws are available and FREE engineering and technical assistance is offered. Contact Northfield Precision Instrument Corp., 4400 Austin Blvd., P. O. Box 550, Island Park, NY 11558-0550. Call Toll Free 1-800-810-2482 - Fax(516) 431-1928; or visit our website at www.northfield.com.
