December 10, 2007 -
With quick-disconnect feature, UMQ Series enables cable to be attached at end of installation process, virtually eliminating potential for damaged cables. If cable does get damaged, it can be replaced in field without replacing entire mat. Mats come in standard sizes with standardized cable location, and 5 or 10 m long cable. When specified minimum weight is applied to mat, switch closes, sending signal to controller, which sends stop signal to guarded machine.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Eliminates the Need to Replace an Entire Safety Mat due to Damaged Cables
Patented quick disconnect feature allows cable to be attached at end of installation process, virtually eliminating the potential for damaged cables
FREMONT, CA - Omron Scientific Technologies, Inc. introduces UMQ Series Safety Mats. These safety mats feature a patented IP67 quick-disconnect cable connector that promises significant cost savings to the user by reducing inventory requirements, while simplifying installation and replacement of damaged cables.
The quick-disconnect feature allows for last minute cable length changes in the field, and since the cable is not attached until the end of the installation process, the potential for cable damage during installation is significantly reduced. And even if a cable is damaged during installation or mat operation, it can simply be replaced in the field without having to replace an entire mat. The quick-disconnect is designed for backward compatibility with the mat cable location of current Omron STI safety mats.
Black UMQ series safety mats are available in standard sizes with a standardized cable location. Mat cables are currently available in 5 meter and 10 meter lengths. Mats are also available in metric sizes, yellow color for greater visibility, special angular and cut outs for uniquely shaped areas, and customized cable locations. All Omron STI safety mats are engineered to satisfy ANSI/RIA R15.06-1999, ISO 13856-1:2001, ANSI B11.19-2003, CSA Z432-04 and EN1760-1:1998 standards.
A safety mat system offers freedom, flexibility, and reduced operator fatigue when compared with traditional guarding methods such as interlocked fences, pullback restraints or perimeter barriers. Full visibility of and access to the work area is maintained.
The safety mat is a simple, normally open switch. When a specified minimum weight is applied to the safety mat the "switch" closes. This sends a signal to the safety mat controller, which in turn, sends a stop signal to the guarded machine. Each safety mat presents four wires to the safety mat controller. This provides the redundancy required to monitor the wires for open circuits due to incorrect wiring or physical damage to the safety mat wires.
Additionally, safety mats can also simplify routine tasks such as machine set-up, maintenance and repair. Typical applications for safety mats include welding robots, assembly machinery, material handling, packaging machinery, punches, presses and robotic work cells.
About Omron STI
Omron Scientific Technologies, Inc. is a North American leading provider of safeguarding, scanning and sensing products and services. Omron STI provides safety products that are used to protect workers around machinery, automated equipment and industrial robots. Additional Omron STI products include scanner and sensor products that are used to improve productivity and product quality in various automated measuring and profiling, parts-related, and vehicle scanning applications.
Engineering:
Russ Wood
USA
Phone: 800221-7060 E-mail this person Company Information: Name: Omron Scientific Technologies Inc. Address: 6550 Dumbarton Circle City: Fremont State: CA ZIP: 94555 Country: USA Phone: 800-479-3658 FAX: 510-744-1442 http://www.sti.com
