Multi-Pin Feedthroughs suit limited space applications.
March 30, 2007 -
Featuring 9 gold-plated pins in straight-through pin-to-pin design, Subminiature-C Feedthroughs can be installed in 1.33 in. CF metal seal and ISO-NW16KF elastomer seal flanges. Ultra High Vacuum units are hermetically sealed and electrically insulated in stainless steel shell using glass-ceramic bonding technology. Air and Vacuum side connectors are fitted with captured stainless steel socket head screws for securely locking to mating feedthroughs.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Accu-Glass Products, Inc. is proud to announce the latest in UHV (Ultra High Vacuum) connectivity solutions: The Subminiature-C feedthrough and related Air and Vacuum side cable assemblies.
Accu-Glass Products Subminiature-C multi-pin hermetic feedthroughs are designed for applications where space is limited or where Subminiature-D connections will not fit. The compact design allows installation into 1.33 inch CF metal seal and ISO-NW16KF elastomer seal flanges.
Nine gold plated pins are in a straight through pin-to-pin design and are hermetically sealed and electrically insulated in a stainless steel shell using the latest in glass-ceramic bonding technology.
Air and Vacuum side connectors are fitted with captured stainless steel socket head screws that provide a means of securely locking them to their mating feedthroughs. On the vacuum side, Kapton insulated cable assemblies fitted with PEEK connectors are available to meet the demands of ultrahigh vacuum environments. In-vacuum connector screws are vented where required and the feedthrough's screw-boss functions as a locating key. Air to vacuum pin position is identified with a permanent surface mark, which clearly locates pin assignments.
Contact:
Accu-Glass Products, Inc.
Chris Miltenberger
700 Arroyo Ave.
San Fernando, CA 91340
818-365-4215
Fax 818-365-7074
