Industrial PC Enclosures are designed for harsh environments.
January 24, 2007 -
W5-XGA15 rugged wall- and bulkhead-mount industrial PC enclosures feature 15 in. TFT XGA LCD with 8-wire resistive touch screen, resolution of 1,024 x 768, and brightness of 250 cd/m˛ with contrast of 400:1. Units include 4 x 90 mm hotswap 49CFM fans and accommodate any PS/2 style power supply. Lockable door is sealed with fabric-covered EMI gasket, and top cover, which protects I/O cables, is interlocked with door to prevent unauthorized access to wiring.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Chassis Plans Releases Innovative Wallmount Chassis with Built-In 15 in. LCD
San Diego, CA - January 22, 2007 - Chassis Plans, The Original Industrial Computer Source, today released the W5-XGA15 family of rugged wall mount and bulkhead mount industrial PC computer enclosures with a 15" XGA TFT LCD and Touch Screen built into the door.
The W5-XGA15 is unique in the market, offering an ATX computer enclosure designed exclusively for wall and bulkhead mounting. Other wallmount computers are simply reworked desktop or rack mount designs. The W5-XGA15 is a clean paper design with no compromises in functionality. Building on the previously successful launch of the W5Chassis, the W5-XGA15 offers a clean user interface for security, control and monitoring applications.
The W5-XGA15 is perfect for a wide variety of applications where an office style computer does not provide appropriate protection and a 19" rack is not available. The W5-XGA15 can be hung exposed on a wall in a factory, in a closet such as a security system, mounted on a drilling rig, and so forth. When the door is closed, it does not look like a computer which has high appeal for theft and vandalism mitigation.
The W5-XGA15 provides an NEC 15" TFT XGA LCD with built-in 8-wire resistive touch screen. The display resolution is 1024x768 in native mode. Display brightness with the touch screen overlay is 250 cd/m2 with a contrast of 400:1. Response time is a fast 16mS and the display supports analog video input.
A lockable door protects the installed components from prying hands. The door is sealed with fabric covered EMI gasket for both EMI and environmental sealing. The high quality locking compression latch sets the EMI gasket when the door is closed. Accessible behind the door is the power and reset switches as well as the power-on and drive activity LED's. A top cover protects the I/O cables and is interlocked with the door to prevent unauthorized access to the wiring. Conduit knockouts are provided on both sides.
The W5-XGA15 is designed for harsh environments and includes four 49CFM fans for cooling. The fans are mounted in hot swap carriers for easy field service. An optional fan monitoring board is available. A large air filter is mounted on the exterior bottom of the enclosure for easy cleaning. Access to the locked interior is not required for cleaning the filter.
The W5-XGA15 system is optimized for a variety of customer specified options including in-door LCD control panels and LCD displays up to 17" 1280x1024 in a vertical orientation. The touch screen can be replaced with anti glare and vandal shields. Alternative touch technologies are also available. Customer specified paint, logo and silk screening are available for private labeling.
Key features of the W5-XGA15 Chassis include:
o EATX (12x13") motherboard mounting - W5-XGA15 models
o Passive backplane mounting - W5000-XGA15 models
o Built-in 15" XGA TFT LCD with 1024 x 768 resolution
o Built-in touch screen
o Two internal 3-1/2" hard drive mounting locations
o Internal 5-1/4" drive tray including a slim floppy/cd adapter
o Accommodates any PS/2 style power supply including redundant and DC input
o Four high flow 90mm hotswap 49CFM fans
o Filtered cooling air
o Universal card hold down system for high vibration environments
o Locking door
o Cover over I/O cables interlocked with front locking door
o Various options for front door mounted LCD control panels
o Options for up to 17" 1280x1024 LCD mounted in door
o Custom paint and logo available
"Working with key customers in the offshore oil exploration industry, Chassis Plans was able to engineer and manufacture a very rugged system for use in harsh environments" said David Lippincott, Founder and Chief Technologist of Chassis Plans. "Hurricane Katrina slammed the offshore drilling rigs and Chassis Plans' wall mount enclosures were some of the few pieces of equipment to survive."
The W5-XGA15 offers a unique blend of versatility and installed component protection in a low cost wall mount system.
The W5-XGA15 is in production. Contact Chassis Plans for pricing. OEM and quantity discounts are available. More information is available at www.chassis-plans.com/w5-xga15.html.
About Chassis Plans
Chassis Plans is a specialized designer and manufacturer of award-winning custom and COTS rack mount computer systems and LCDs for critical industrial and embedded applications such as telephony, imaging, instrumentation, control and other environments which require performance, ruggedness and reliability. Integrating Long Life Industrial Motherboards and other high quality components into Chassis Plans' industrial enclosures provides customers with stable long availability products.
Chassis Plans products are manufactured in the USA to CE and UL standards, satisfying the industry's increasing demands for features and performance. All Chassis Plans products are backed by a full two-year warranty and Chassis Plans' engineer-oriented technical support. Chassis Plans is recognized as the fastest growing technology company in San Diego and by the Inc 500 List. Please visit www.chassis-plans.com for more information or e-mail at saleseng@chassisplans.com. Company Information: Name: Chassis Plans Inc. Address: 8295 Aero Place City: San Diego State: CA ZIP: 92123 Country: USA Phone: 858-571-4330 FAX: 858-571-6146 http://www.chassisplans.com
