June 26, 2006 -
Available in 2- and 3-axis specifications, TT Table Top robot's rigid, extruded aluminum base; ball screw; and servo control motor allow for positioning repeatability of ±0.02 mm. Its 3-axis configuration comes with Z-axis brake and lets users perform 3D arc interpolation and path movement. Available as Gate Type with fixed Y axis or as Cantilever Type with open work surface, robot stores up to 64 programs and runs up to 16 programs simultaneously.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
IAI launched its state of the art high performance TT Table Top Robot with a full range of new design features for improved performance.
The Adoption of a rigid base, ball screw and servo control motor allows for tight tolerances of Positioning Repeatability of ±0.02 mm. The TT Table Top Robot employs a rigid base made of aluminum-extruded material. It also uses a high-accuracy ball screw and a servo control motor to allow precision and eliminate mis-stepping.
The TT Table Top Robot utilizes the high path accuracy and constant speed of the X-SEL controller.
With the 3-axis specification, the TT table Top robot lets you perform three-dimensional arc interpolation and path movement. You can also use the TT Table Top Robot together with a teaching pendant, PC software of other tools. A maximum of 64 programs can be stored, and up to 16 programs can be run simultaneously. Up to 3,000 positions can be registered to the Built-in X-SEL Controller
The Table Top Robot comes with a choice of two models Gate Type or Cantilever Type. The gate type has its Y-axis fixed, so it withstands unbalanced loads and is suitable in applications where the Z-axis receives a heavy load, as well as applications where a large portion of the load overhands the slider. The cantilever type provides a wide, open work surface, so it is ideal when the equipment is required to handle larger loads or loads with an irregular shape in a fixed condition.
In addition to offering two model types (gate type and cantilever type), the TT Table Top Robot also provides two selectable operating ranges. Choose 200 mm x 200 mm (2020 type) or 400 mm x 400 mm (4040 type) as the operating range (X-axis / Y-axis) or the actuator.
The TT Table Top is available in a 2-axis specification and a 3-axis specification. The 3-axis specification comes standard with a Z-axis brake, which prevents the slider from falling when the power is off.
The TT Table Top Robot can also be connected to a common field network such as DeviceNet, CC-Link, ProfiBus, and Ethernet for the transmission and acquisition of position changes, production results and other data.
Technical CAD drawings, PDF files and data sheets detailing the measurements and specifications of each TT Table Top Robot are available for download at www.intelligentactuator.com or by requesting the new TT Robot Printed Catalog.
About IAI - Intelligent Actuator
IAI - Intelligent Actuator is a member of is a member of the RIA, SEMI, and AHTD organizations. IAI Manufacturers a full range of IX Scara Robots, Linear Actuators,RoboCylinders,TableTopRobots,Controllers, Cartesian Robots, Single Axis Robots, and Linear Positioners
The company is ISO 9001 certified, and its products conform to European RoHS directives. IAI headquarters is in Japan but distributes throughout the USA, and worldwide.
For more information, please contact IAI at 800 736 1712 or visit www.intelligentactuator.com email ajimenez@iaius.com Contact Antonio Jimenez.
