DAQ System combines LVDT and digital signal conditioner.
April 18, 2006 -
CellMite Quad, Model 4336, is 4-channel instrument that connects directly to 2 ac LVDT transducers and 2 dc strain gage force transducers and provides direct digital data input into PC serial port. Precision ac sine wave excitation voltages to power LVDTs and precision dc excitation voltages to power force strain gage bridges are generated by unit. System features CellView Multi-Unit GUI software and applies internal signal conditioning with filtering to all channels.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
CellMite Quad AC/DC Mixed LVDT and Force Measurement Digital Signal Conditioner
The CellMite Quad AD/DC mixed LVDT (Linear Variable Differential Transformer) and Force Measurement Digital Signal Conditioner, Model 4336, is a 4-channel instrument that connects directly to two AC LVDT transducers and two DC strain gage force transducers and provides direct digital data input into the serial port of a PC. Precision AC sine wave excitation voltages to power the LVDTs and precision DC excitation voltages to power the force strain gage bridges are generated by the unit. Internal signal conditioning with filtering is applied to all channels and the digitized data is sent in serial form to a standard PC.
CellMite Quad generates two +/-10V analog outputs to track user-selected LVDT and force channels. CellView Multi-Unit GUI software completes the data acquisition system with synchronized data storage of all channels in an Excel file, and real-time viewing of all channels utilizing up to 8 user-specified software displays.
CellMite Quad compensates each channel's transducer nonlinearities using its integrated 6-point calibration capability. The unit has full range tare capability for the LVDT and strain gage force channels, and dual internal precision shunt resistors for the force channels.
CellMite Quad offers nonvolatile memory for parameter and calibration storage, selection between 3 stored LVDT calibrations for the two LVDT channels and selection between 3 stored force transducers for the two strain gage force channels. Also featured: multi-point and mV/V calibration, remote sense excitation, 24-bit internal resolution with 16-bit analog output, and RS232 serial data output.
Company Name: Electro Standards Laboratories
Address 1: 36 Western Industrial Drive
City: Cranston
State: RI
Zip: 02921
Phone: 401-943-1164
URL: www.electrostandards.com
Marketing:
Jeannette Gouin Marketing Manager
USA
Phone: 401-943-1164 E-mail this person Company Information: Name: Electro Standards Laboratories Address: 36 Western Industrial Dr. City: Cranston State: RI ZIP: 02921 3403 Country: USA Phone: 401-943-1164 FAX: 401-946-5790 http://www.electrostandards.com
