Static Mixer flattens head loss over varying flow rates.
Static Mixer flattens head loss over varying flow rates.
January 6, 2006 -
Suitable for any fluid handling system, variable flow Model 2900 utilizes 2 in-line wafer type mixers, one fixed with 0.9 Beta ratio and one variable with 0.7 Beta ratio and that adjusts incrementally to adapt to changing flow conditions. Featuring automatic modulation to maintain 3 psi regardless of flow rate, mixer flattens head loss at max flow, while providing consistent mixing over 20:1 turndown ratio. Sizes range from 3/8-120 in. ID.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Variable Flow Static Mixer Flattens Head Loss Over Varying Flow Rates
A new variable flow static mixer that is suitable for any fluid handling system and optimizes mixing while minimizing head loss is being introduced by Westfall Manufacturing Company of Bristol, Rhode Island.
The Westfall Model 2900 Variable Flow Static Mixer utilizes two in-line wafer type mixers: one fixed and one variable that adjusts incrementally to adapt to changing flow conditions. Featuring automatic modulation to main-tain 3 psi, regardless of flow rate, this static mixer flattens head loss at maximum flow, while providing consistent mixing over a 20:1 turndown ratio.
Available in sizes from 3/8" to 120" I.D., the Westfall Model 2900 Variable Flow Static Mixer's fixed mixer has a 0.9 Beta ratio and the variable mixer has a 0.7 Beta ratio. Separated by a distance equal to two pipe diameters; as the flow velocity increases, the variable mixer opens to reduce excessive head loss. The patented static mixer plate's design creates a combination of vortex shedding and intense shear zone turbulence with a short laying length.
The Westfall Model 2900 Variable Flow Static Mixer is priced from $ 4,000.00 to $ 300,000.00 (list), depending upon size and material of construction. Literature and price quotations are available upon request.
For more information contact:
Westfall Manufacturing Company
Robert Glanville, Marketing Director
16 Peckham Dr. / P.O. Box 7
Bristol, RI 02809-0007
(888) 928-3747 FAX (401) 253-6530
e-mail: info@westfallmfg.net www.westfallmfg.com
