December 15, 2005 -
Series VJ (flat cover) and RVJ (raised cover) Platinum Plus enclosures are made of halogen free, hot molded, glass fiber reinforced polyester and can withstand continuous temperatures from -58 to 302°F. Available in 7 sizes with inner dimensions from 6 x 6 in. to 18 x 16 in., enclosures are offered in platinum color for UV resistance. Gaskets are seamless polyurethane foam, and various window, hinge, vent, and latching options are available.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Vynckier is pleased to introduce our new color "Platinum Plus" for our VJ and RVJ Series Enclosures.
The color, like the precious metal that it is named after, has great physical properties!
The newer light grey color is cleaner, cooler and more aesthetically pleasing. Now users can enjoy the physical benefits of better heat reflection and better UV resistance, due to the lighter color.
o VJ (flat cover) and RVJ (raised cover) enclosures are designed in accordance with the Joint Industrial Council (JIC) - USA
o Enclosures are maintenance free and corrosion resistant
o Seven sizes are available ranging from inside dimensions of 6" x 6" to 18" x 16"
o The bases and covers are made of halogen free, hot molded, glass fiber reinforced polyester that can withstand continuous temperatures from -58°F up to 302°F
o Gaskets are seamless polyurethane foam
o Enclosures can be modified to customer specifications
Applications
VJ and RVJ enclosures are designed for use as electrical junction boxes in highly corrosive environments. Examples include: Oil Refineries, Chemical Processing Plants, Waste Water Treatment Plants, Marine Installations, Electroplating Plants, Agricultural Environments, and Food Processing Plants, etc.
These enclosures are highly suitable as instrument housings in both indoor and outdoor applications. Window enclosure provides easy visual inspection of interior components.
Options & Accessories
o Window Options
- Bonded
- Clear View
- Gasketed
o Hinged Front Panels
o Hinge Options
o Latching Options
- W HW HWLL HWPL
o Vent Options
- MEDV
- Louver
o Enclosure Modifications
Standards
IEC 439-1
IEC 529 - Rated IP66-11
CSA Certified per C22.2 No. 94
EN 50298
Approvals
UL Listed types: 3, 3R, 4, 4X, 12 & 13 per UL 508
CSA Listed types: 3, 3R, 4, 4X, 12 & 13
AS Listed types: 3131 - 1991
