July 26, 2005 - Compression and extension dampers are force-absorbing devices used where load or door must be lowered or swung in controlled motion at constant speed. Products are offered in rod/tube diameter sizes from .24 x .59 in. to .315 x .87 in., with stroke lengths from 2–7 in., extended lengths from 7.9–19.7 in., and max load capacities from 50–100 lb. Custom dampers are available in lengths to 26 in. with stroke to 10 in, and all dampers may be double-damped.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
RONKONKOMA, NY — H. A. Guden Co., Inc. has introduced a full line of compression and extension dampers to assist designers and engineers with their motion control needs. Guden dampers are used primarily where a heavy load or door must be lowered or swung in a controlled motion at a constant speed. For example, dampers prevent a door from being slammed shut, or from being pulled or swung wildly open.
Guden dampers supplement their gas springs to provide a complete selection of lifting, lowering and dampening options. While similar in appearance to gas springs, dampers are force-absorbing instead of force-supplying devices. Two types are offered to control speed in either compression or extension, depending on the mounting position.
In Guden dampers, a piston with a small orifice must pass through hydraulic oil, thus controlling speed. They are made in rod/tube diameter sizes from .24" by .59" to .315" by .87". with stroke lengths from 2" to 7", extended lengths from 7.9" to 19.7" and maximum load capacities from 50 lb to 100 lb load per damper. Heavy, medium heavy, medium, medium light and light damping dampers are all available.
Custom dampers are available in lengths up to 26" with a stroke of up to 10". All dampers are available on special order "double-damped" - damped in both compression and extension.
Technical drawings, purchasing and immediate delivery are all available by phone, fax and online at www.guden.com.
Established in 1920, Guden is an ISO 9000:2000 Registered Company. For more information, contact H. A. Guden Co., Inc., 99 Raynor Avenue, Ronkonkoma, NY 11779-6634, 800-344-6437 or Fax 631-737-2933, info@guden.com, www.guden.com.
Contacts:
Public Relations:
Bernie Famorca
USA Company Information: Name: Guden, H. A., Co., Inc. Address: 99 Raynor Ave., P.O. Box 146 City: Ronkonkoma State: NY ZIP: 11779 Country: USA Phone: 888-764-3766 FAX: 631-737-2933 http://www.guden.com
