Air Separator prevents material contact with screen.
September 17, 2003 - Slant Screen Separator directs conveyed material into baler, collector bag, or compactor. By capturing up to 100% of waste material and ensuring unrestricted airflow through puncture-resistant, perforated steel screen, separator virtually eliminates trim carryover. Design eliminates air pressure and dangerous turbulence in drop chutes and downstream equipment. Adjustable inlet-airfoil enables personnel to set optimal air velocity.
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Innovative Slant Screen Separator Prevents Material Contact With Screen for Maximum Air and Momentum Removal
Air Separator Captures Up To 100% Of Conveyed Waste Material
Proprietary Design Cuts Maintenance Needs, Prevents Line Shutdowns
Newark, DE: A Slant Screen Separator from trim waste and scrap solution provider Precision AirConvey, Newark, Del., directs up to 100% of conveyed material into a baler, collector bag, box, compactor or other waste container while preventing the screen contact that causes blinding and hinders efficiency in less sophisticated systems. Developed for separating nonwovens, films, corrugated board and other materials from conveying air, the versatile Slant Screen Separator features a proprietary design that eliminates air pressure and dangerous turbulence in drop chutes and downstream equipment. By capturing up to 100% of the waste material and ensuring unrestricted airflow through a puncture-resistant, perforated steel screen, the low-maintenance Slant Screen Separator virtually eliminates trim carryover, saves energy and cuts associated downtime for cleaning and maintenance.
Engineered to permit on-site customization at converting, printing and other facilities, the Slant Screen Separator includes an adjustable inlet-airfoil enabling operations personnel to set optimal air velocity and a damper to permit on-the-fly flow pattern adjustments to maintain efficiency while accommodating material changes. For safe, easy flow monitoring, the advanced Slant Screen Separator boasts a large viewing window and access panel. The Slant Screen Separator may be installed in new production lines or retrofit on existing systems, indoors or outdoors.
For technical information and sales inquiries, contact Chris Peterson, Precision AirConvey, 210 Executive Drive #6, Pencader Corporate Center, Newark, DE 19702; 302.999.8000; Fax 302.266.7559; www.precisionairconvey.com; get-facts@airconvey.com
