Multicore ARM® SBCs combine graphics, industrial I/O.

WinSystems, Inc.    Arlington, TX 76011
May 08, 2013 Available with single-, dual-, or quad-core Freescale™ i.MX 6 series Cortex™-A9 processors, 800 MHz SBC35-C398 series has 102 x 146 mm footprint and operates from 10–50 Vdc or PoE input. Video engines can drive 3 simultaneous display interfaces while maintaining communications and control functions. I/O options include Gigabit Ethernet with IEEE-1588™ support, USB 2.0, serial, and CAN interfaces. IO60 connector, supporting I²C, SPI, TTL-UART, and PWM signals, allows stackable expansion.

PC/104-Plus 2-Channel Gigabit Ethernet Card supports POE.

WinSystems, Inc.    Arlington, TX 76011
Apr 05, 2013 Implemented as PC/104-Plus add-in I/O module, PPM-GIGE-2-POE can manage power to remotely located POE devices or board stacks. Solution integrates 2 independent Gigabit Ethernet ports with Power Sourcing Equipment (PSE) circuits. Both POE interfaces can use separate external DC supplies or share one external power source. Operating from -40° to +85°C, 3.6 x 3.8 in. module uses RJ-45 connectors to plug into 10/100/1000Mbps networks using CAT5 unshielded twisted pair copper cables.

PoE Powered Device works with PC/104+ computer board stack.

WinSystems, Inc.    Arlington, TX 76011
Feb 25, 2013 As Power over Ethernet Powered Device (PoE-PD) DC/DC supply for PC/104-Plus compatible computer board stack, PPM-PS397-POE-1 can be configured as endpoint or midspan device. This 25 W PD extracts power from twisted pair Cat 5 Ethernet cable and conforms to IEEE 802.3af PoE standard. Onboard, isolated DC/DC converter operates from 42–57 V input and generates 3 output voltages: +5, +12, and -12 Vdc. Device also accepts DC input from 16–60 V via auxiliary connector; auxiliary input is dominant.

Dual Channel PC/104 CAN Module provides 1,000 V isolation.

WinSystems, Inc.    Arlington, TX 76011
Feb 19, 2013 Available with Windows and Linux drivers, Model PCM-CAN-2-ISO employs high-speed isolated data couplers and power supplies to provide 1,000 V protection between two NXP SJA1000 CAN controllers and network interface. Each CAN channel can provide isolated +5 Vdc power or receive isolated +5 to +12 Vdc power from interface for additional flexibility. Operating from -40 to +85°C, PCM-CAN-2-ISO supports transfer rates to 1 Mbps and has jumper selectable termination resistors.

PC/104-Plus SBC operates from -40 to +85°C.

WinSystems, Inc.    Arlington, TX 76011
Feb 01, 2013 Based on Intel® 1.66 GHz Atom™ N455 and ICH-8M System Controller Hub with up to 2 GB of DDR3 system memory, Model PPM-C393-S is suited for security, Mil/COTS, medical, transportation, DAQ, and communications applications. Board includes Gigabit Ethernet port, simultaneous CRT and LVDS flat panel video support, 8 USB 2.0 ports, 4 serial COM ports, SATA controller, and PATA controller for CompactFlash socket. Support for PC/104 and PC/104-Plus expansion connectors allows I/O modules to be added.

Industrial ATX Power Supply serves PC/104, EPIC, and EBX SBCs.

WinSystems, Inc.    Arlington, TX 76011
Oct 17, 2012 Measuring 198 x 97 x 40.5 mm, convection-cooled, 150 W model PS-ATX150-0 powers embedded SBCs that support ACPI specification for device configuration and power management by OS. Support for ATX signals Power On/Off, Power Good, and Power Fail lets SBCs utilize sleep/suspend modes for energy conservation during periods of processor or system inactivity. While it accepts 90–264 Vac, 47–63 Hz input, power supply generates 5 DC output voltages: +3.3 V, +5 V, +5 V Standby, +12 V, and -12 V.

PC/104 DC/DC Power Supplies support off-grid computing.

WinSystems, Inc.    Arlington, TX 76011
Sep 28, 2012 Suitable for remote applications requiring renewable power sources, PS394 Series supports 2 inputs from solar panels, wind turbines, or other DC sources. Units include controller for battery charging and UPS operation. Measuring 90 x 96 mm, boards comes in PC/104 and PC/104-Plus configurations that accept voltages from dual 9–32 Vdc input sources and automatically select and convert highest to output voltage. Modules require only convection cooling while operating from -40° to +85°C.

PCIe SUMIT DIO Module combines high density and performance.

WinSystems, Inc.    Arlington, TX 76011
Aug 21, 2012 SUMIT-ISM(TM)-compatible PXM-UIO96-2 offers PCIe expansion on 90 x 96 mm, PC/104-sized module enabled by stackable, high-speed SUMIT(TM) connector. Card offers ability to monitor all 96 lines for both rising and falling digital edge transitions, latch them, and interrupt host processor to deliver change-of-input status notification. Each I/O line is programmable for input, output, or output with read-back operation, and transition polarity is programmable and enabled on bit-by-bit basis.

PC/104-Size GbE Module offers high-speed networking connectivity.

WinSystems, Inc.    Arlington, TX 76011
Aug 13, 2012 Intended for SFF, industrial embedded applications, 90 x 96 mm PXM-GIGE connects to 10/100/1000 Mbps networks using CAT5 UTP copper cables and offers stackable PCIe expansion on PC/104 module with addition of high-speed SUMIT connector. This Gigabit Ethernet module, based on Intel® 82573 controller, plugs directly into SUMIT-ISM(TM) compatible products and supports Linux, Windows®, and other x86-compatible RTOSs.

Open Frame Panel PC integrates resistive touchscreen.

WinSystems, Inc.    Arlington, TX 76011
Jul 19, 2012 Available with single-core 1.66 GHz N455 or dual core 1.8 GHz D525 single board computer based on Intel® Atom(TM) processor, Model PPC3-12 features 12.1 in. diagonal color TFT with viewing angle of ±80° and replaceable LED backlight. Flat panel display supports XGA 1024 x 768 pixels and has luminance of 500 cd/m². Operating from -30 to +70°C without fan, PC includes wired Ethernet connection plus expansion option for 802.11 wireless Ethernet and/or CDMA/GSM cellular modems.
