Industrial Vacuum Cleaner transfers liquid to drum at 1-2 gps.

Vac-U-Max    Belleville, NJ 07109
Sep 19, 2012 Model TK-01 is designed for high-speed transfer of viscous liquids directly into closed top 55 gal drum. Operating on plant compressed air, product consumes 35 scfm at 60 psig. It includes Auto Vac cutoff, which prevents operator from overfilling drum, and can be used for coolant or cleaning out sumps, tanks, and machine sludge. Unit fits directly on holes of closed-top, vacuum-tight drum.

Conveying System handles light density powders.

Vac-U-Max    Belleville, NJ 07109
May 27, 2009 Built for conveying fumed silica, diatomaceous earth, and micro ballons, VAC-U-MAX POWD'r PUMP'r helps in moving them without creating fugitive dust and lumping. System incorporates bag dump station with 5 Cf capacity hopper, and integral dust collector with 1.5 hp fan that uses PTFE coated pleated polyester felt filters to maximize filtration and product release. Small footprint plug-and-play system comes standard with lift up door with gas springs for operator safety.

Positive Displacement Vacuum Pumps use large area filters.

Vac-U-Max    Belleville, NJ 07109
Jan 15, 2008 Using cartridge filter to protect pump, VAC-U-MAX PD Pump Packages exhibit smooth and quiet operation and are available from 3-100 hp. They come with cartridge filter, OSHA-approved belt guard, Glycerin-filled vacuum gauge, silencer, and high-vacuum relief valve. Suited for existing vacuum conveying systems or central vacuum cleaning systems, packages are also offered with options such as differential pressure switch and sound enclosures.

Industrial Vacuum Cleaner extends filtration systems.

Vac-U-Max    Belleville, NJ 07109
Jan 07, 2008 Air-operated VAC-U-MAX 55MW is steel constructed vacuum system suitable for cleaning liquids with metal chips or shavings in metalworking industry. Solid particles are separated from collected liquid with VAC-U-MAX Chip Basket and Liner. Dual swivel casters and compact size of 26 in. wide allows vacuum to position close to machine tools and sumps while keeping hoses as short as possible. System is available as pump-out cart for users who own 55 gal drum-top vacuums.

Industrial Vacuum Cleaner uses continuous bagging system.

Vac-U-Max    Belleville, NJ 07109
Oct 10, 2006 Eliminating drum handling, continuous-duty Model MDL850 comes equipped with filter cleaning system that does not require compressed air, and enables filters to be cleaned without shutting vacuum cleaner down. When filters are being cleaned, discharge valve opens and automatically discharges collected product into continuous bagging system. Model MDL850 features heavy-duty frame, and is compact enough to allow up to 3 operators to work in 50 ft area.

Central Vacuum Cleaner supports up to 3 users.

Vac-U-Max    Belleville, NJ 07109
Dec 28, 2005 Designed for simultaneous use by up to 3 operators, Model 1041-8.5 is equipped with large area cartridge filter with PTFE coating for handling fine powders. In addition to manual push-button pulse filter cleaning, system features quiet, 8.5 hp regenerative blower; roll-away 55 gal collection drum with dolly; and lifting frame with hydraulic jack.

Central Vacuum System handles high dust applications.

Vac-U-Max    Belleville, NJ 07109
Oct 18, 2005 Using positive displacement pump, heavy-duty Model 2120 collects debris directly into 55 gal drum. It features 36 in. dia filter housing with 230 ft² of filter area, comprising cloth-to-air ratio less than 3:1 to minimize stress on filters. Teflon® coating provides slick filter surface that facilitates release of debris, preventing material build-up and filter blinding. Continuous pulse filter cleaning and off line filter cleaning maximize filter efficiency.

Industrial Air Powered Vacuum is intrinsically safe.

Vac-U-Max    Belleville, NJ 07109
Aug 24, 2005 Featuring HEPA filter and stainless steel cover, Model 55 2-JET 55 gal twin venturi vacuum picks up hazardous, dusty material in presence of solvent vapors. It offers chemically resistant static-conductive vacuum hose, and HEPA filtration is rated 99.97% efficient on particles as small as 0.3 micron. When equipped with liquid shutoff valve, vacuum picks up liquid solvents, such as Toluene, Methanol, and Xylene, at rates up to 2 gal/sec.

Batch Weigh Convey System achieves ±.25–1 lb accuracy.

Vac-U-Max    Belleville, NJ 07109
Aug 09, 2005 Batch Weigh Convey System allows materials to be metered into customer's process by loss-in-weight to maintain accuracy during transfer of dry powders. Material is first conveyed into vacuum receiver by gain-in-weight. When desired batch is reached, system switches to loss-in-weight, allowing PLC control panel to dispense correct amount desired. Weights discharged are usually over 5-10 lb and up to thousands of pounds of material.
