High-Speed Shrinksleeve Labeler meets high-volume demand.

PDC International Corp.    South Norwalk, CT 06854
Nov 06, 2012 Able to apply shrinksleeves at speeds from 500–600 labels/min on single inline head, PDC R-500 TS-CB Shrinklabeler incorporates continuous, steady state movement of sleeving materials during cutting and application process. All motions are continuous, minimizing internal machine and dynamic forces to promote stable, high-speed operation. Along with proprietary blade assembly, mandrel-style labeler features tool-less changeover and is engineered for 24/7 operation.

Steam Tunnel features over 1,000 inches of live shrink area.

PDC International Corp.    South Norwalk, CT 06854
Aug 22, 2012 Featuring dual-wall, dual-zone design, Model KST 140-712 is engineered for packagers of food, beverages, and personal care products that require 300 cpm capacity without complexity of multiple tunnels. System provides 5 pairs of steam tubes in each of 2 zones. Each row is externally adjustable for steam volume, flow, and rotary position. For precise steam regulation, tunnel utilizes condensate traps, steam filtration, step-down regulators, steam valve, and electronic regulator.

Cup and Tub Shrink Labeler combines speed ease of changeover.

PDC International Corp.    South Norwalk, CT 06854
May 07, 2012 Able to process up to 400 containers/min, PDC R-400 handles round, oval, and square (including tapered) tubs; cups and bowls; as well as range of rigid packages. Design facilitates configuration into multipacker and accommodate packages with capacities from 2 oz to ½ gal. Depending on container, applicator can receive product right side up or upside-down, and graphics can extend fully in both directions. Mandrel-style labeler is suited for thin films from 1.5-2 mils.

Adjustable Steam Tunnel operates at up to 200 cpm.

PDC International Corp.    South Norwalk, CT 06854
Jan 26, 2012 Featuring stainless dual wall construction, Model KST 80A-712 with Steam Venting Package is compatible with wide range of containers, including those that are challenging to shrink consistently. Dual-zone system has 5 rows of steam distribution tubes on each side, each externally adjustable for steam volume, flow, and rotary position. Monitoring tunnel temperatures in real-time, Electronic Regulator makes continuous adjustments in steam release to compensate for thermal loads of incoming product.

Blade Assemblies offer alternative to spinning knives.

PDC International Corp.    South Norwalk, CT 06854
Dec 15, 2011 Custom-engineered for cutting and perforating operations in tamper-evident banders and shrink sleeve labelers, PDC blade assemblies are manufactured from tool steels for wearability, toughness, flatness, and edge profile uniformity. Blades operate dust-free; eliminate hairs typical of spinning knife systems while delivering precise cuts for months, even under continuous, high-speed conditions; and can be re-sharpened multiple times. Double-edged (reversible) versions are available.

Shrink Sealer features dual-head configuration.

PDC International Corp.    South Norwalk, CT 06854
Sep 19, 2011 Offering true 24/7, downtime-free performance with aid of automated Reel Changeover feature, 90-2 Shrink Sealer features dual-head capability that enables sealing of 400+ containers/min(cpm). Variable-speed system can also run as slowly as 100 cpm per head to synchronize with production. Able to apply single-layer and multilayer PVC, PETG, PLA, and OPS bands in gauges as thin as 40 micron, system has compatible diameter range of .375-3.0 in. and height range of .625-8 in.

Shrink Sealing Systems apply tamper-evident banding.

PDC International Corp.    South Norwalk, CT 06854
Aug 09, 2011 Featuring stainless steel frame, upstream photo-eyes, and Allen Bradley touchscreen interface, 50 Series ShrinkSealers apply tamper-evident banding and shrink sleeve labeling at up to 130 cpm, continuously. Systems run 40-50 micron banding materials and are compatible with all petroleum-based and sustainable films, including PVC, PET, PETG, OPS, and PLA films. Material can range from .375-3 in. D and .625-7 in. H. Modules for both vertical and horizontal perforations are available.

Multipacker Machine provides 24/7 uptime performance.

PDC International Corp.    South Norwalk, CT 06854
May 27, 2011 Operating at speeds up to 350 cpm, Model R-300A has Zero-Downtime feature that allows it to run while film is being spliced between rolls. To achieve this, PDC Accumulator Module accumulates film while ramping down run speed for 60 sec. Machine also offers tool-less size changeover, SIKO digital indicator dials, and motorized machine head height with preset positions. Accommodating straight-wall and hourglass containers, multipacker is suited for rigid packages, cartons, bottles, and cans.

Packaging Machine applies tamper-evident shrinkbands to tubs.

PDC International Corp.    South Norwalk, CT 06854
Dec 10, 2009 Without using vacuum, pneumatics, or spinning knives, F-160 Evolution Shrinkbander applies shrinkbands 1-2.3 in. in height and 2.5-6.75 in. dia around lids of tapered and straight-wall tubs used for food and dairy products. Fully mechanical solution uses dual servos for product handling and sleeve feeding. Offered in 3 standard models with line speeds from 30-400 cpm, product incorporates touchscreen interface, static eliminator, low material sensor, and Mitsubishi PLC control.

Shrink Sleever/Labeler produces tamper-evident seals.

PDC International Corp.    South Norwalk, CT 06854
Nov 17, 2009 Operating at 50-170 cpm, 60 Series Evolution Shrinksealer applies full-height bodysleeves and tamper-evident banding to jars, bottles, and products of all types. Use of 2 servos for product handling and sleeve registration promotes flexibility. Sleeve label can be designed to extend up over cap, with horizontal perforation for consumer tamper evidence, and shrink sleeves can also be applied as neck bands around upper portion of container and its closure or as full-height safety seals.
