Tube Cutter processes flexible tubing to tight specifications.

The Eraser Company, Inc.    Syracuse, NY 13221
Apr 24, 2013 Featuring 10 feed rates, WC601D Rotary Blade Tube Cutter is capable of processing materials such as flexible polyurethane, flexible PVC, nylon reinforced hose, and rubber hose to programmed length and number of pieces. Adjustable belt feed and rotary cutter ensure there is no crushing of material, either along length or on cut ends. Batching feature allows all parameters for frequently run jobs to be pre-programmed, while kitting feature allows collection of batches to be run sequentially.

Flexible Tube Cutter handles range of materials, thicknesses.

The Eraser Company, Inc.    Syracuse, NY 13221
Mar 20, 2013 Able to cut 1 1/8–¼ in. material, 120 V Model FTC1 Flexible Tube Cutter offers unlimited maximum cut length and minimum cut length of 2.00 in. Design facilitates usability while also promoting production flexibility. Cutter is capable of processing range of material types, including tygon, radiator hose, flexible PVC, polyurethane, silicone, nylon, PTFE, FEP, PFA, polyethylene, polypropylene, rubber, vinyl, and polystyrene.

Automatic Wire and Tubing Cutter offers 9 variable feed rates.

The Eraser Company, Inc.    Syracuse, NY 13221
Mar 08, 2013 With 0.050–99.999 in. cut length range, Model WC302 accurately cuts wire, tubing, and sleeving to programmed length and number of pieces. Unit handles tubing up to 0.250 in. OD and wire up to 12 AWG/14 AWG (stranded/solid). Batching feature allows all variables for frequently run jobs to be pre-programmed, while kitting feature allows for multiple pieces of different lengths to be cut within batch. Up to 99 batches and 10 kits can be programmed. At cut lengths under 2 in., tolerance is ±0.01 in.

Multi-Material Cutter offers max cutting force of 600 lb.

The Eraser Company, Inc.    Syracuse, NY 13221
Feb 18, 2013 Able to produce round or flat material up to 3.94 in. wide and 5/8 in. thick, Model MMC200 can cut copper wire/cable, silver solder, power cords, cellophane, fiberglass sleeving, latex, fabrics, belting, flat/ribbon cable, strapping, hosing, and tubing. Microprocessor-controlled unit can be programmed to cut any length with 1% or better tolerance reliant on material construction. Programmable for up to 99 batches and 10 fixed feed rates, MMC200 is rated to cut up to 7,592 two inch pieces/hr.

Wire and Cable Reeler/Dereeler offers motorized operation.

The Eraser Company, Inc.    Syracuse, NY 13221
Dec 08, 2009 Enabling operators to wind wire and cable without fatigue and quickly de-reel it with no pulling, Model DE600M features 1/6 hp motor that turns shaft at constant speed of 57½ rpm (47 rpm for 220 V units) and can handle reels of material weighing up to 75 lb. Adjustable cones and dog allow use of reels with arbor holes from ¾ to 2 1/8 in. OD, and included handle facilitates manual reeling and de-reeling if required.

Coaxial Cable Stripper offers efficient, portable design.

The Eraser Company, Inc.    Syracuse, NY 13221
Oct 15, 2009 Designed for portability and weighing only 2 lb, Model 824 Coaxial Cable Stripper can strip cables including RGU, semi-rigid, plenum, heliax, and more, as well as semi-rigid cable up to .141 in. OD. It features standard battery pack that provides about 200 strips/charge. Carrying case, charger, and adapter cord are included.

Wire and Flexible Tubing Cutter offers automated operation.

Eraser Company, Inc., The    Syracuse, NY 13221
Feb 17, 2009 Able to cut wire, tubing, sleeving, and more to programmed length and number of pieces, WC302 supports 9 variable feed rates for choosing correct rate for any given material to optimize production rate, repeatability, and cut length accuracy. As many as 99 batches may be programmed, each containing all variables for specific frequently run jobs. Also included, kitting feature allows for multiple pieces of different lengths to be cut within one batch; up to 10 kits can be programmed.

Multi Material Cutter delivers 600 lb of cutting force.

The Eraser Company, Inc.    Syracuse, NY 13221
Nov 20, 2008 Microprocessor-controlled MMC200 cuts round or flat material up to 3.94 in. wide and 5/8 in. thick and can be programmed to cut any length (in. or mm), with 1% or better tolerance. It is also programmable for up to 99 batches and 10 fixed feed rates. MMC200 is rated to cut up to 7,592, 2-in. pieces/hr through makerials such as copper wire and cable, silver solder, power cords, cellophane, fiberglass sleeving, latex, fabrics, belting, flat and ribbon cable, strapping, hosing and tubing.

Rotary Blade Tubing Cutter has 5 variable feed rates.

Eraser Company, Inc., The    Syracuse, NY 13221
Jun 29, 2006 Model WC601D can cut materials such as flexible polyurethane, flexible PVC, nylon reinforced hose, and rubber hose from ½ to 1 1/8 in. OD. Belt feed eliminates crushing of tubes along their length as well as on cut ends, while programmable batching feature can retain 99 programs in memory. Rotary cutting head consistently produces clean, square cuts that conform to tight specifications as required for medical applications.

Reelers and Dereelers produce neat wire and cable coils.

Eraser Company, Inc., The    Syracuse, NY 13221
Jan 13, 2006 Available with coil weight capacities from 55-150 lb, models CW10, CW20, and CW30 incorporate adjustable friction clutch to prevent overruns in dereeling operations. Products have variable coil dimensions (IDs) from 5-27 in. as well as capacity lengths from 1,000 ft of 1/8 in. dia wires up to 300 ft of ¾ in. dia wires. Uses include dereeling, measuring, cutting, and reeling operations by production kitters, jobbers, and electrical contractors.
