Short Wave IR Camera suits military imaging applications.

Goodrich Corp.    Charlotte, NC 28217
May 01, 2012 Consuming 1.5 W, Model GA640C-15A integrates into handheld, helmet, or weapon mounted surveillance devices and unmanned aircraft. Uncooled SWIR detector images in real-time, daylight to low light, through smoke, haze, and fog. Operating from -35 to +71°C, C-platform camera features 640 x 512 pixel resolution with 15 micron pitch and 0.9-1.7 micron spectral range. Camera Link® digital output offers plug-and play, 12-bit imagery for viewing, digital processing, and/or transmission.

Camera Microgimbal has multiple stabilization features.

Goodrich Corp.    Charlotte, NC 28217
Oct 20, 2011 Supplied in 7 in. package, TASE400 is suited for day/night imaging in manned and unmanned Intelligence Surveillance and Reconnaissance (ISR) applications. It features mid-wave infrared camera (MWIR) with continuous zoom from 20°-2° field of view, 36X zoom daylight camera, fiber optic gyros, and electronic stabilization techniques. Third payload bay is configurable as standard to host options such as laser rangefinder, pointer, or designator.

Video Processing System stabilizes images, tracks targets.

Goodrich Corp.    Charlotte, NC 28217
Jun 22, 2011 Bringing together video processing, image stabilization, and target tracking, VPS II increases stability and image range of Goodrich TASE gimbal products or similar gimbaled camera systems of other manufacturers. Capabilities let users designate and track objects along complex paths, when they are concealed, and when object is transitioning. Functionality enhances identification of objects in images taken from moving platforms such as UAVs, towers, and manned aircraft.

InGaAs SWIR Uncooled Video Camera has Mil-hardened design.

Goodrich Corp.    Charlotte, NC 28217
Sep 01, 2010 Imaging through atmospheric obscurants such as fog, haze, and smoke, SU640HSX offers 0.9-1.7 µm sensitivity in SWIR as well as optional NIR/SWIR extended spectral range sensitivity of 0.7-1.7 µm. Solid-state imager, with 640 x 512 pixel format and 25 micron pitch, operates from -40 to +70°C and consumes less than 2.7 W at 20°C. Capabilities enable real-time daylight to low-light imaging in SWIR for 24/7 passive surveillance and laser detection.

Low-SWaP SWIR Camera enhances unmanned vehicles.

Goodrich Corp.    Charlotte, NC 28217
Aug 30, 2010 With total volume of less than 4.9 in.³ and weight of less than 4.5 oz, small SWaP (size, weight, and power) shortwave infrared (SWIR) camera enables 24 hr imaging capabilities for unmanned vehicles. InGaAs technology enables camera to see light wavelengths from 0.7-1.7 µm, while additional capabilities let user detect and track range of military lasers, day or night, with optimal clarity. Product can fit most unmanned aerial or ground vehicles.

SWIR Digital Line Scan Camera performs high-speed imaging.

Goodrich Corp.    Charlotte, NC 28217
May 11, 2010 With line rate to 91,900+ lines/sec, SU1024LDH2 InGaAs camera suits spectral-domain optical coherence tomography (SD-OCT) applications. It measures 3 x 3 x 2.4 in. and can capture detailed 3D SD-OCT volumes in 1.05 microns wavelength band. Along with operator-selectable trigger modes and integrate-while-read snapshot acquisition, 1,024 pixel camera offers wavelength response from over 0.8 microns to 1.7 microns with 25 micron pixel pitch and aperture heights of 25 or 500 microns.

Camera Gimbal System suits helicopters in small municipalities.

Goodrich Corp.    Charlotte, NC 28217
Feb 24, 2010 Intended for surveillance and inspection, TASE Gimbal System consists of stabilized camera gimbal, software, and FAA-approved mount for aircraft. System collects video during flight that can be displayed in real-time in cockpit. Configurable video and map displays for pilot, combined with autonomous tracking and anomaly tagging, minimize flight crew workload. Images are recorded and synchronized with GPS image position, so precise pinpointing for follow-up happens automatically.

Software provides in-field data intelligence snapshots.

Goodrich Corp.    Charlotte, NC 28217
Jul 25, 2008 Used during day or night, Intelligence Reference Library integrates data from diverse unrelated sources to provide real-time battlefield intelligence on PC. As sensors focus on mission-specific geographic location, software formulates imagery intelligence picture of actionable data on ground-based work station or handheld PC. Solution is simultaneously catalogues and meshes data from diverse sources such as DB-110 reconnaissance pod, synthetic aperture radar, and full motion video.

Day/Night Camera detects NIR-SWIR light for military.

Goodrich Corp.    Charlotte, NC 28217
Mar 20, 2008 Available packages with 320 x 256 or 640 x 512 resolution, NIR/SWIR night vision and laser detection camera uses indium gallium arsenide-night vision (InGaAs-NV(TM)) technology to detect and track range of battlefield IR lasers. Products can see light wavelengths from 0.7-1.7 µm, near infrared (NIR) to shortwave infrared (SWIR), and are suited for integration into military night vision and laser detection systems as well as industrial machine vision systems.

InGaAs SWIR Video Cameras consume less than 2 W of power.

Goodrich Corp.    Charlotte, NC 28217
Jun 04, 2007 Model SU320KTS-1.7RT provides response from 0.9-1.7 micron, while Model SU320KTSVis-1.7RT features extended wavelength response into visible from 0.4-1.7 micron. Providing simultaneous 12-bit Camera Link® digital and EIA-170 analog outputs, lightweight units are available with 320 x 256 pixel format on 25 micron pitch, automatic gain control, and built-in non-uniformity corrections. Snapshot feature provides image capture from pulsed events or moving objects within one frame.
