Radio Test System supports wideband power sensors.

Aeroflex    Irvine, CA 92618
Mar 19, 2013 With addition of through-line Bird 5017 Wideband Power Sensor, 3550 Radio Test System optimizes accuracy for in-field test applications. Bird 5017 supports frequency ranges from 25 MHz to 1 GHz, with power accuracy of ±4% of reading. Sensor provides power measurements and detection for true average/peak power and duty cycle, and uses these precise measurements to calculate other important factors, such as VSWR, return loss, reflection coefficient, crest factor, average burst power, and CCDF.

Digital Radio Test System features color touchscreen.

Aeroflex    Irvine, CA 92618
Aug 22, 2012 Designed for Professional Mobile Radio, public safety, and other land mobile radio applications, Model 3550 isolates problems and assesses performance in AM/FM radios, with options for P25, DMR, NXDN(TM), and dPMR radio systems. Internal battery enables 4.5 hr of continuous operation in temperatures from -0 to +50°C. Equipped with -140 dBm spectrum analyzer, test system features phase noise of -95 dBc/Hz, RF signal generator level accuracy of ±1.5 dB, and FM deviation meter accuracy of 4%.

Communications Tester features interference cancellation.

Aeroflex    Irvine, CA 92618
Jul 26, 2012 Supporting all key LTE-A features of 3GPP Release 10, TM500 LTE-A Test Mobile platform includes enhanced Inter Cell Interference Cancellation, which optimizes performance of heterogeneous network deployments where nodes of different types-macro-, micro- and picocells-have coverage areas that partially overlap. System can be used to verify correlation between measurements reported by User Equipment and eNodeB signaling, verifying benefits of interference management.

Signal Generators and Analyzers offer IEEE 802.11ac capability.

Aeroflex    Irvine, CA 92618
Jul 03, 2012 Featuring 200 MHz bandwidth, SGD RF Digital Signal Generators and SVA Vector Signal Analyzers offer 802.11ac capability, suitable for engineers in WLAN research, design, and manufacturing. Systems provide level and frequency settling times of 100 µs and low phase noise performance of -135 dB/Hz at 1 GHz, 20 kHz offset. Combining 2 instruments within 19 in. width, S-Series allows both transmit and receive functions. Using Aerolock(TM), instruments can be locked together to build complex test set-ups.

Mobile Test Device emulates Cat5 user equipment.

Aeroflex    Irvine, CA 92618
Mar 13, 2012 TM500 LTE test mobile emulates LTE category 5 user equipment, allowing carriers to verify network operation and equipment vendors to test performance of their eNodeB (LTE base stations) at higher data rates that are enabled by Cat5 handsets and terminals. TM500 provides demodulation and decoding of downlink signals transmitted in 4x4 MIMO, and transmission of uplink signals modulated using 64 QAM, in support of these higher LTE data rates.

Modular RF Test System supports 802.11ac WLAN mobile devices.

Aeroflex    Irvine, CA 92618
Feb 14, 2012 Supporting transmitter and receiver testing within one PXI modular RF test system, PXI 3000 Series is intended for silicon vendors, WLAN board integrators, consumer electronics device manufacturers, and contract manufacturers. Modules support wideband signal analysis and generation for frequencies up to 6 GHz, covering bandwidth and frequency requirements of 802.11ac. Providing GUI, Aeroflex PXI Studio application software generates and analyzes 802.11a, b, g, n, and ac signals.

Modular RF Test Systems support FM and ZigBee analysis.

Aeroflex    Irvine, CA 92618
Aug 09, 2011 With Generic Measurement Suite, designated PXI 3030 Option 111, test and development engineers using PXI 3000 Series systems can perform variety of generic analyses of analog and digital modulated signals. Initial release supports analysis of broadcast FM signals as well as Phase Shift Keying modulation types. Supported measurements include modulation accuracy, adjacent channel power, occupied bandwidth, and spectrum mask measurements for continuous burst signals.

Analog RF Signal Generators feature avionics waveforms.

Aeroflex    Irvine, CA 92618
Jun 09, 2011 SGA Signal Generator with Option 6 offers internal generation of waveforms required for testing avionics functions. Option includes waveforms for Instrument Landing Systems (ILS), VHF Omni-directional Radio (VOR), marker beacons, and COM ID tones for airport identification. Digitally generated modulating waveforms ensure accurate and stable performance under all operating conditions. Respective operating frequency ranges for SGA Models 3 and 6 are 100 kHz to 3 GHz and 100 kHz to 6 GHz.

LTE Digital Radio Test Set aids multi-mode development.

Aeroflex    Irvine, CA 92618
Jun 09, 2011 In addition to handling data call hand-over between LTE and HSPA, Aeroflex 7100 LTE Digital Radio Test Set supports Option 103, which provides test capabilities for GSM/GPRS, and Option 105, which extends capability to include WCDMA and HSPA. Device provides manufacturers of cellular terminals and chipsets with unified test environment in which to fully test all radio access technologies supported by DUT.

Digital Radio Test Set simultaneously tests voice and data.

Aeroflex    Irvine, CA 92618
Mar 29, 2011 With Option 104, 7100 LTE Digital Radio Test Set provides simultaneous emulation of LTE data and 1X CDMA voice, known as SV-LTE, to facilitate mobile handset testing. Engineers can verify Data throughput/performance to determine any impact on speed or latency, as well as Voice to ensure there is no loss of audio or audio clipping due to processing load. Users can also confirm that both RAT protocols operate successfully and do no impact each other's message exchange or timing.
