Stand-Alone EM Solver suits 3D planar design applications.

Applied Wave Research Inc.    El Segundo, CA 90245
Oct 04, 2007 Helping to diagnose issues early and shorten design process, AXIEM(TM) delivers electromagnetic (EM) analysis as true upfront design technology. Open boundary, non-gridded, method-of-moments solver supports true thick metal in layered dielectric media. Solver algorithm - multipole method adapted for full-wave analysis - scales on order of N log(N) and enables user to simulate to DC. Other features include meshing algorithms and auto-calibrated internal ports.

PDK is suited for UltraCMOS(TM) process.

Applied Wave Research Inc.    El Segundo, CA 90245
Sep 13, 2006 Developed for analog and RFIC design, UltraCMOS Process Design Kit (PDK) in Analog Office 2006 software shortens IC development cycles and accelerates tape-out to CMOS SOS process. It is based on GA and GC variants of UltraCMOS process which enables combination of high-performance RF, mixed-signal, passive elements, nonvolatile memory, and digital functions on single device without blocking capacitors.

Software provides RF architectural planning tool.

Applied Wave Research Inc.    El Segundo, CA 90245
Sep 07, 2006 With RFA(TM), communications designers can determine initial specifications for radio design. RF Budget Analysis(TM) enables users to make RF cascaded measurements, such as gain, noise figure, and third-order intercept along communication link. RF Inspector(TM) technology consists of frequency-domain simulation tool that helps determine root cause of heritage of any inter-modulation product of RF link and includes effects of conversions, harmonics, inter-modulation, and noise.

Process Design Kit targets high-frequency wireless ICs.

Applied Wave Research Inc.    El Segundo, CA 90245
Jun 16, 2006 Analog Office 2006, used to design analog and RFIC wireless and wirelined communications products, helps shorten IC development cycles and accelerate tape-out to IHP's silicon germanium (SiGe) process. This AWR-based IHP process design kit (PDK) includes complete set of schematic symbols, simulation models, and fully parameterized layout cells characterized to match IHP process performance. IHP SG25H1 0.25 µm BiCMOS process includes NpN HBTs up to fT/fmax = 180/220 GHz.

EDA Software facilitates RFIC design.

Applied Wave Research Inc.    El Segundo, CA 90245
Apr 18, 2006 Built on interactive AWR Design Environment(TM), Analog Office(TM) 2006 provides open RF design platform with 5 electromagnetic simulators, 4 circuit simulators, and a complete physical design and verification toolset. It includes Intelligent Net(TM) technology, which powers on-the-fly interconnect extraction, and physical layouts of hundreds of thousands of devices can be opened and viewed in seconds. Also included, design flow and validated process design kits enable multiple tape-outs.

Software facilitates RF and microwave design.

Applied Wave Research, Inc.    El Segundo, CA 90245
Sep 23, 2004 Microwave Office® 2004 provides unified design environment that is inherently synchronized with schematic, simulation, and layout data. It fully integrates 3D planar electromagnetic simulation with circuit simulation and layout tools, permitting arbitrary physical structures to be embedded within linear and nonlinear circuit simulations. Through AWR EM Socketâ„¢ interface, 3rd party EM solvers are integrated with, and directly accessible from, AWR unified data model.

Software suits next-generation analog and RFIC designs.

Applied Wave Research, Inc.    El Segundo, CA 90245
May 24, 2004 Analog Office® 2004 IC design system provides open and unified design environment, offering full interaction with comprehensive set of integrated tools. Analog Office 2004 toolset spans from system-level to circuit-level design and verification, for complete high-frequency design. Features include support for Linux platform, extension of AWR Intelligent Netâ„¢ for handling arbitrary layout geometries, and support for Verilog-A analog behavioral language.

EDA Software supports Linux platform.

Applied Wave Research, Inc.    El Segundo, CA 90245
May 06, 2004 Visual System Simulator 2004 embodies time-based complex envelope simulation engine coupled with circuit simulation tool integrated in AWR Design Environmentâ„¢. Product provides phase lock loop simulation blocks for interactive investigation of dynamics of frequency synthesizers and frequency/phase modulators. RF budget analysis enables designers to calculate cascaded performance of RF link. Software includes adaptive behavioral models such as LMS and RLS equalizers.

Software focuses on total RF closure.

Applied Wave Research, Inc.    El Segundo, CA 90245
May 28, 2003 Analog Officeâ„¢ utilizes concurrent interconnect-driven and RF-aware design methodology that is built around Intelligent Netâ„¢ technology in unified design environment. Design suite is integrated into existing digital and mixed signal IC design flows and solves gigahertz analog RFIC challenges. Integrated simulation technology allows users to combine simulation techniques while using consistent set of validated models.

Software focuses on RF closure.

Applied Wave Research, Inc.    El Segundo, CA 90245
Mar 25, 2003 Microwave Officeâ„¢ 2003 simulation, layout, and electromagnetic analysis suite provides monolithic microwave integrated circuit, RF, and microwave engineers with harmonic balance simulator, time-domain simulation engines, and EM Socketâ„¢ interface. It provides development process for design of wireless and high-speed wired applications by improving simulation capabilities, and closing verification loop with links to test and measurement instruments.
